82761 877U1000

Active

Belden Inc.

CABLE 2COND 22AWG NATURAL

Search across all available documentation for this part.

Active

Belden Inc.

CABLE 2COND 22AWG NATURAL

Technical Specifications

Parameters and characteristics for this part

Specification	82761 877U1000

Cable Type	Multi-Conductor
Conductor Insulation	Fluorinated Ethylene-Propylene (FEP)
Conductor Material	Copper, Tinned
Conductor Strand [custom]	7
Conductor Strand [custom]	30 AWG
Features	Drain Wire
Jacket (Insulation) Diameter [diameter]	3 mm
Jacket (Insulation) Diameter [diameter]	0.118 in
Jacket (Insulation) Material	Low Smoke Poly-Vinyl Chloride (LSPVC), Plenum
Jacket (Insulation) Thickness	0.015 in
Jacket (Insulation) Thickness	0.381 mm
Jacket Color	Natural
Length	1000 ft
Length	304.8 m
Number of Conductors	2
Shield Coverage	100 %
Shield Material	Aluminum
Shield Type	Foil
Voltage	300 V
Wire Gauge	22 AWG

Part	Conductor Strand [custom]	Conductor Strand [custom]	Features	Conductor Insulation	Number of Conductors	Shield Type	Conductor Material	Shield Material	Shield Coverage	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Jacket Color	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Material	Length	Length	Voltage	Wire Gauge	Cable Type
Belden Inc. 82761 877U1000	7	30 AWG	Drain Wire	Fluorinated Ethylene-Propylene (FEP)	2	Foil	Copper Tinned	Aluminum	100 %	0.015 in	0.381 mm	Natural	3 mm	0.118 in	Low Smoke Poly-Vinyl Chloride (LSPVC) Plenum	1000 ft	304.8 m	300 V	22 AWG	Multi-Conductor

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Spool	1000	$ 1.90

General part information

2 (1 Pair Twisted) Conductor Multi-Conductor Cable Natural 22 AWG Foil 1000.0' (304.8m)
