AM3N-2415DH30-RZ
Activeaimtec
DC DC CONVERTER +/-15V 3W
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
AM3N-2415DH30-RZ
Activeaimtec
DC DC CONVERTER +/-15V 3W
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | AM3N-2415DH30-RZ |
|---|---|
| Applications | ITE (Commercial) |
| Approval Agency | CE |
| Current - Output (Max) | 100 mA |
| Current - Output (Max) | 100 mA |
| Efficiency | 78 % |
| Mounting Type | Through Hole |
| Number of Outputs | 2 |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | 24-DIP Module |
| Power (Watts) | 3 W |
| Size / Dimension [x] | 31.8 mm |
| Size / Dimension [x] | 1.25 " |
| Size / Dimension [y] | 0.8 in |
| Size / Dimension [y] | 20.3 mm |
| Size / Dimension [z] | 0.4 " |
| Size / Dimension [z] | 10.2 mm |
| Type | Isolated Module |
| Voltage - Input (Max) [Max] | 26.4 V |
| Voltage - Input (Min) [Min] | 21.6 V |
| Voltage - Isolation | 3000 V |
| Voltage - Output 1 [Max] | 15 V |
| Voltage - Output 1 [Min] | -15 V |
| Voltage - Output 2 | -15 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tube | 1 | $ 13.06 | |
| 5 | $ 12.96 | |||
| 10 | $ 12.87 | |||
| 20 | $ 12.67 | |||
| 40 | $ 12.52 | |||
| 80 | $ 12.30 | |||
| 160 | $ 12.08 | |||
Description
General part information
AM3N Series
Isolated Module DC DC Converter 2 Output -15 ~ 15V -15V 100mA, 100mA 21.6V - 26.4V Input
