Specification	XCV400E-6BG560C0773

Mounting Type	Surface Mount
Number of Gates	569952
Number of I/O	404
Number of LABs/CLBs	2400
Number of Logic Elements/Cells	10800
Operating Temperature (Max)	85 °C
Operating Temperature (Min)	0 °C
Package / Case	560-LBGA Exposed Pad, Metal
Package Length	42.5 mm
Package Name	560-MBGA
Package Width	42.5 mm
Total RAM Bits	163840 bits
Voltage - Supply (Maximum)	1.89 V
Voltage - Supply (Minimum)	1.71 V

XCV400E Series

Part	Number of Logic Elements/Cells	Voltage - Supply (Maximum)	Voltage - Supply (Minimum)	Package Width	Package Name	Package Length	Number of I/O	Mounting Type	Number of LABs/CLBs	Operating Temperature (Max)	Operating Temperature (Min)	Number of Gates	Package / Case	Total RAM Bits
AMD / Xilinx XCV400E-6BG560C	10800	1.89 V	1.71 V	42.5 mm	560-MBGA	42.5 mm	404	Surface Mount	2400	85 °C	0 °C	569952	560-LBGA Exposed Pad Metal	163840 bits
AMD / Xilinx XCV400E-6BG560C0773	10800	1.89 V	1.71 V	42.5 mm	560-MBGA	42.5 mm	404	Surface Mount	2400	85 °C	0 °C	569952	560-LBGA Exposed Pad Metal	163840 bits
AMD / Xilinx XCV400E-6BG560I	10800	1.89 V	1.71 V	42.5 mm	560-MBGA	42.5 mm	404	Surface Mount	2400	100 °C	-40 °C	569952	560-LBGA Exposed Pad Metal	163840 bits
AMD / Xilinx XCV400E-8PQ240C	10800	1.89 V	1.71 V	32 mm	240-PQFP	32 mm	158	Surface Mount	2400	85 °C	0 °C	569952	240-BFQFP	163840 bits
AMD / Xilinx XCV400E-8BG432C	10800	1.89 V	1.71 V	40 mm	432-MBGA	40 mm	316	Surface Mount	2400	85 °C	0 °C	569952	432-LBGA Exposed Pad Metal	163840 bits
AMD / Xilinx XCV400E-7BG560C	10800	1.89 V	1.71 V	42.5 mm	560-MBGA	42.5 mm	404	Surface Mount	2400	85 °C	0 °C	569952	560-LBGA Exposed Pad Metal	163840 bits
AMD / Xilinx XCV400E-6PQ240I	10800	1.89 V	1.71 V	32 mm	240-PQFP	32 mm	158	Surface Mount	2400	100 °C	-40 °C	569952	240-BFQFP	163840 bits
AMD / Xilinx XCV400E-6BG432C	10800	1.89 V	1.71 V	40 mm	432-MBGA	40 mm	316	Surface Mount	2400	85 °C	0 °C	569952	432-LBGA Exposed Pad Metal	163840 bits
AMD / Xilinx XCV400E-7PQ240C	10800	1.89 V	1.71 V	32 mm	240-PQFP	32 mm	158	Surface Mount	2400	85 °C	0 °C	569952	240-BFQFP	163840 bits
AMD / Xilinx XCV400E-7BG432C	10800	1.89 V	1.71 V	40 mm	432-MBGA	40 mm	316	Surface Mount	2400	85 °C	0 °C	569952	432-LBGA Exposed Pad Metal	163840 bits
