MAXM22510EVKIT#
ActiveAnalog Devices Inc./Maxim Integrated
EVAL MAXM22510
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
MAXM22510EVKIT#
ActiveAnalog Devices Inc./Maxim Integrated
EVAL MAXM22510
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | MAXM22510EVKIT# | MAXM22510 Series |
|---|---|---|
| Contents | Board(s) | Board(s) |
| Data Rate | - | 500 kbps |
| Duplex | - | Full |
| Embedded | False | False |
| Function | RS422, RS485 | RS422, RS485 |
| Mounting Type | - | Surface Mount |
| Operating Temperature | - | -40 °C |
| Operating Temperature | - | 105 ░C |
| Package / Case | - | 44-BFLGA |
| Protocol | - | RS422, RS485 |
| Receiver Hysteresis | - | 20 mV |
| Supplied Contents | Board(s) | Board(s) |
| Supplier Device Package | - | 44-LGA (9.35x11.5) |
| Type | Interface | Transceiver, Interface |
| Utilized IC / Part | MAXM22510 | MAXM22510 |
| Voltage - Supply | - | 3.6 V |
| Voltage - Supply | - | 3 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 149.71 | |
MAXM22510 Series
IC TRANSCEIVER FULL 1/1 44LGA
| Part | Receiver Hysteresis | Voltage - Supply [Max] | Voltage - Supply [Min] | Operating Temperature [Min] | Operating Temperature [Max] | Data Rate | Protocol | Duplex | Supplier Device Package | Mounting Type | Package / Case | Type | Embedded | Utilized IC / Part | Function | Supplied Contents | Contents |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Analog Devices Inc./Maxim Integrated MAXM22510GLH+ | 20 mV | 3.6 V | 3 V | -40 °C | 105 ░C | 500 kbps | RS422, RS485 | Full | 44-LGA (9.35x11.5) | Surface Mount | 44-BFLGA | Transceiver | |||||
Analog Devices Inc./Maxim Integrated MAXM22510EVKIT# | Interface | MAXM22510 | RS422, RS485 | Board(s) | Board(s) | ||||||||||||
Analog Devices Inc./Maxim Integrated MAXM22510GLH+T | 20 mV | 3.6 V | 3 V | -40 °C | 105 °C | 500 kbps | RS422, RS485 | Full | 44-LGA (9.35x11.5) | Surface Mount | 44-BFLGA | Transceiver |
Description
General part information
MAXM22510 Series
MAXM22510 RS422, RS485 Interface Evaluation Board
