MEZS84801A
ActiveMONOLITHIC POWER SYSTEMS (MPS)
MEZ PLUG AND PLAY 48V, 12W, POE POWER SUPPLY, IEEE 802.3AF COMPLIANT
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
MEZS84801A
ActiveMONOLITHIC POWER SYSTEMS (MPS)
MEZ PLUG AND PLAY 48V, 12W, POE POWER SUPPLY, IEEE 802.3AF COMPLIANT
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | MEZS84801A |
|---|---|
| Applications | ITE (Commercial) |
| Current - Output (Max) [Max] | 1 A |
| Efficiency | 84.5 % |
| Features | OVP, OCP, OTP |
| Mounting Type | Surface Mount |
| Number of Outputs | 1 |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | 0 °C |
| Package / Case | 20-SMD Module |
| Power (Watts) | 12 W |
| Size / Dimension [x] | 45 mm |
| Size / Dimension [x] | 1.77 in |
| Size / Dimension [y] | 39 mm |
| Size / Dimension [y] | 1.54 " |
| Size / Dimension [z] | 0.68 in |
| Size / Dimension [z] | 17.3 mm |
| Type | Isolated PoE Module |
| Voltage - Input (Max) [Max] | 57 V |
| Voltage - Input (Min) [Min] | 37 V |
| Voltage - Output 1 | 12 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tray | 1 | $ 33.32 | |
| 6 | $ 33.06 | |||
| 12 | $ 32.80 | |||
| 30 | $ 32.29 | |||
| 42 | $ 30.75 | |||
| 84 | $ 28.19 | |||
| 234 | $ 27.68 | |||
Description
General part information
MEZS84801 Series
Isolated PoE Module DC DC Converter 1 Output 12V 1A 37V - 57V Input
