31514 0104000

Active

Belden Inc.

HOOK-UP STRND 14AWG BLACK

Search across all available documentation for this part.

Active

Belden Inc.

HOOK-UP STRND 14AWG BLACK

Technical Specifications

Parameters and characteristics for this part

Specification	31514 0104000

Cable Type	Hook-Up
Conductor Material	Copper, Tinned
Conductor Strand [custom]	41
Conductor Strand [custom]	30 AWG
Jacket (Insulation) Diameter [diameter]	4.29 mm
Jacket (Insulation) Diameter [diameter]	0.169 in
Jacket (Insulation) Material	Neoprene
Jacket (Insulation) Thickness	1.19 mm
Jacket (Insulation) Thickness	0.047 in
Jacket Color	Black
Length [x]	1219.2 m
Length [x]	4000 ft
Ratings	UL Style 3046
Voltage	600 V
Wire Gauge	13.5 AWG

Part	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Ratings	Cable Type	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Jacket (Insulation) Material	Jacket Color	Wire Gauge	Voltage	Conductor Material	Length [x]	Length [x]	Conductor Strand [custom]	Conductor Strand [custom]
Belden Inc. 31514 0104000	4.29 mm	0.169 in	UL Style 3046	Hook-Up	1.19 mm	0.047 in	Neoprene	Black	13.5 AWG	600 V	Copper Tinned	1219.2 m	4000 ft	41	30 AWG
Belden Inc. 31514 0044000	4.29 mm	0.169 in	UL Style 3046	Hook-Up	1.19 mm	0.047 in	Neoprene	Yellow	13.5 AWG	600 V	Copper Tinned	1219.2 m	4000 ft	41	30 AWG

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Spool	4000	$ 1.32

General part information

14 AWG Hook-Up Wire 41/30 Black 600V 4000' (1219.2m)

Technical documentation and resources
