R10-E6X2-V700

Active

TE Connectivity Potter & Brumfield Relays

RELAY GEN PURPOSE DPDT 5A 24V

Search across all available documentation for this part.

Active

TE Connectivity Potter & Brumfield Relays

RELAY GEN PURPOSE DPDT 5A 24V

Technical Specifications

Parameters and characteristics for this part

Part	Relay Type	Contact Material	Coil Voltage	Contact Form	Operating Temperature [Max]	Operating Temperature [Min]	Mounting Type	Coil Resistance	Coil Type	Contact Rating (Current)	Termination Style	Must Operate Voltage	Switching Voltage	Approval Agency	Coil Current
TE Connectivity Potter & Brumfield Relays R10-E6X2-V700	General Purpose	Silver Cadmium Oxide (AgCdO)	24 VDC	DPDT (2 Form C)	75 ░C	-55 °C	Socketable	700 Ohms	Non Latching	5 A	Plug In	18 VDC	120 VAC	CSA UR	34.3 mA
TE Connectivity Potter & Brumfield Relays R10-E6X2-115V	General Purpose	Silver Cadmium Oxide (AgCdO)	115 VAC	DPDT (2 Form C)	75 ░C	-55 °C	Socketable	9 kOhms	Non Latching	5 A	Plug In	86 VAC	120 VAC	CSA UR	12.8 mA
TE Connectivity Potter & Brumfield Relays R10-E6X2-V185	General Purpose	Silver Cadmium Oxide (AgCdO)	12 VDC	DPDT (2 Form C)	75 ░C	-55 °C	Socketable	185 Ohms	Non Latching	5 A	Plug In	9 VDC	120 VAC	CSA UR	64.9 mA

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	350	$ 42.82

General part information

General Purpose Relay DPDT (2 Form C) 24VDC Coil Socketable
