A782MN686M1JLAV035

Active

KEMET

CAP ALUM HYBRID 68UF 20% 63V SMD

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet A782MN686M1JLAV035 Spec

A782MN686M1JLAV035

Active

KEMET

CAP ALUM HYBRID 68UF 20% 63V SMD

Deep-Dive with AI

DocumentsDatasheet A782MN686M1JLAV035 Spec

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	A782MN686M1JLAV035

Applications	Automotive
Capacitance	68 µF
ESR (Equivalent Series Resistance)	35 mOhms
Features	Anti-Vibration
Height - Seated (Max) [Max] [z]	11 mm
Height - Seated (Max) [Max] [z]	0.433 in
Lifetime @ Temp.	4000 Hrs
Mounting Type	Surface Mount
Operating Temperature [Max]	135 °C
Operating Temperature [Min]	-55 °C
Package / Case	Radial, Can - SMD
Ratings	AEC-Q200
Ripple Current @ High Frequency	3.05 A
Ripple Current @ Low Frequency	671 mA
Size / Dimension [diameter]	10 mm
Size / Dimension [diameter]	0.394 in
Surface Mount Land Size [x]	0.425 "
Surface Mount Land Size [x]	10.8 mm
Surface Mount Land Size [y]	10.3 mm
Surface Mount Land Size [y]	0.406 "
Tolerance	20 %
Type	Hybrid
Voltage - Rated	63 V

A782MN Series

Part	Features	Ripple Current @ High Frequency	Size / Dimension [diameter]	Size / Dimension [diameter]	Operating Temperature [Max]	Operating Temperature [Min]	Voltage - Rated	Surface Mount Land Size [y]	Surface Mount Land Size [y]	Surface Mount Land Size [x]	Surface Mount Land Size [x]	Mounting Type	Applications	Capacitance	ESR (Equivalent Series Resistance)	Ratings	Type	Tolerance	Lifetime @ Temp.	Package / Case	Ripple Current @ Low Frequency	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]
KEMET A782MN686M1JLAV035	Anti-Vibration	3.05 A	10 mm	0.394 in	135 °C	-55 °C	63 V	10.3 mm	0.406 "	0.425 "	10.8 mm	Surface Mount	Automotive	68 µF	35 mOhms	AEC-Q200	Hybrid	20 %	4000 Hrs	Radial Can - SMD	671 mA	11 mm	0.433 in
KEMET A782MN157M1VLAS025		3.6 A	10 mm	0.394 in	135 °C	-55 °C	35 V	10.3 mm	0.406 "	0.406 in	10.3 mm	Surface Mount	Automotive	150 µF	25 mOhm	AEC-Q200	Hybrid	20 %	4000 Hrs	Radial Can - SMD	1.44 A			0.413 in	10.5 mm
KEMET A782MN157M1VLAV025	Anti-Vibration	3.6 A	10 mm	0.394 in	135 °C	-55 °C	35 V	10.3 mm	0.406 "	0.425 "	10.8 mm	Surface Mount	Automotive	150 µF	25 mOhm	AEC-Q200	Hybrid	20 %	4000 Hrs	Radial Can - SMD	1.44 A	11 mm	0.433 in
KEMET A782MN686M1JLAS035		3.05 A	10 mm	0.394 in	135 °C	-55 °C	63 V	10.3 mm	0.406 "	0.406 in	10.3 mm	Surface Mount	Automotive	68 µF	35 mOhms	AEC-Q200	Hybrid	20 %	4000 Hrs	Radial Can - SMD	671 mA			0.413 in	10.5 mm
KEMET A782MN107M1HLAV030	Anti-Vibration	3.3 A	10 mm	0.394 in	135 °C	-55 °C	50 VDC	10.3 mm	0.406 "	0.425 "	10.8 mm	Surface Mount	Automotive	100 µF	30 mOhms	AEC-Q200	Hybrid	20 %	4000 Hrs	Radial Can - SMD	726 mA	11 mm	0.433 in

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tape & Reel (TR)	3000	$ 0.55

Description

General part information

A782MN Series

68 µF 63 V Aluminum - Polymer Capacitors Radial, Can - SMD 35mOhm 4000 Hrs @ 135°C
