IMM0212D05

Active

XP POWER

DC DC CONVERTER +/-5V 2W

Search across all available documentation for this part.

Active

XP POWER

DC DC CONVERTER +/-5V 2W

Technical Specifications

Parameters and characteristics for this part

Part	Voltage - Output 2	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [z]	Voltage - Output 1	Features	Package / Case	Package / Case	Voltage - Input (Max) [Max]	Operating Temperature [Max]	Operating Temperature [Min]	Control Features	Efficiency	Power (Watts)	Applications	Type	Number of Outputs	Mounting Type	Voltage - Input (Min) [Min]	Voltage - Isolation	Current - Output (Max)	Current - Output (Max)	Current - Output (Max) [Max]
XP POWER IMM0212D05	-5 V	21.8 mm	0.36 "	9.2 mm	0.86 in	0.44 "	11.1 mm	5 V	OCP OVP Remote On/Off SCP	6 Leads	8-SIP Module	18 V	100 °C	-20 C	Active High Enable	79 %	2 W	Medical	Isolated Module	2	Through Hole	9 V	1.5 kV
XP POWER IMM0212D03	-3.3 V	21.8 mm	0.36 "	9.2 mm	0.86 in	0.44 "	11.1 mm	3.3 V	OCP OVP Remote On/Off SCP	6 Leads	8-SIP Module	18 V	100 °C	-20 C	Active High Enable	79 %	2 W	Medical	Isolated Module	2	Through Hole	9 V	1.5 kV	303 mA	303 mA
XP POWER IMM0212S15		21.8 mm	0.36 "	9.2 mm	0.86 in	0.44 "	11.1 mm	15 V	OCP OVP Remote On/Off SCP	5 Leads	8-SIP Module	18 V	100 °C	-20 C	Active High Enable	79 %	2 W	Medical	Isolated Module	1	Through Hole	9 V	1.5 kV			133 mA

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Isolated Module DC DC Converter 2 Output 5V -5V 200mA, 200mA 9V - 18V Input
