LV8773-E

Obsolete

Sanyo

MOTOR DRIVER IC

Search across all available documentation for this part.

Obsolete

Sanyo

MOTOR DRIVER IC

Technical Specifications

Parameters and characteristics for this part

Specification	LV8773-E

Applications	General Purpose
Current - Output	2 A
Function	Driver - Fully Integrated, Control and Power Stage
Interface	Parallel
Motor Type - AC, DC	Brushed DC
Motor Type - Stepper	Bipolar
Mounting Type	Through Hole
Operating Temperature [Max]	85 C
Operating Temperature [Min]	-20 °C
Output Configuration	Half Bridge (4)
Package / Case	28-SDIP Exposed Pad
Package / Case	12.7 mm
Package / Case	0.5 in
Step Resolution	1, 0.5
Supplier Device Package	28-HDIP
Technology	BiCDMOS
Voltage - Load [Max]	32 V
Voltage - Load [Min]	9 V
Voltage - Supply [Max]	5.5 V
Voltage - Supply [Min]	0 V

MOTOR DRIVER IC

Part	Interface	Function	Technology	Motor Type - AC, DC	Mounting Type	Output Configuration	Current - Output	Operating Temperature [Min]	Operating Temperature [Max]	Package / Case	Package / Case	Package / Case	Applications	Motor Type - Stepper	Voltage - Load [Max]	Voltage - Load [Min]	Supplier Device Package	Voltage - Supply [Max]	Voltage - Supply [Min]	Step Resolution
Sanyo LV8773-E	Parallel	Driver - Fully Integrated, Control and Power Stage	BiCDMOS	Brushed DC	Through Hole	Half Bridge (4)	2 A	-20 °C	85 C	28-SDIP Exposed Pad	12.7 mm	0.5 in	General Purpose	Bipolar	32 V	9 V	28-HDIP	5.5 V	0 V	0.5, 1

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tube	44	$ 6.93

General part information

Bipolar Motor Driver BiCDMOS Parallel 28-HDIP
