FSP250M-KBA

Active

FSP Technology Inc.

AC/DC DESKTOP ADAPTER 19V 250W

Search across all available documentation for this part.

Active

FSP Technology Inc.

AC/DC DESKTOP ADAPTER 19V 250W

Technical Specifications

Parameters and characteristics for this part

Specification	FSP250M-KBA

Applications	Medical
Approval Agency	CE, FCC, cULus, TUV, VCCI
Cord Length	36 in
Cord Length	0.91 m
Current - Output (Max) [Max]	13.16 A
Efficiency	Level VI
Form	Desktop (Class I)
Input Connector	IEC 320-C14
Input Type	Cord
No Load Power Consumption [Max]	150 mW
Operating Temperature [Max]	60 °C
Operating Temperature [Min]	-20 C
Output Connector	Rectangular, 6 Position
Power (Watts)	250 W
Region Utilized	International
Standard Number	60601-1
Voltage - Input [Max]	264 VAC
Voltage - Input [Min]	80 VAC
Voltage - Output	19 V

AC/DC DESKTOP ADAPTER 19V 250W

Part	Power (Watts)	No Load Power Consumption [Max]	Voltage - Input [Max]	Voltage - Input [Min]	Efficiency	Approval Agency	Input Connector	Input Type	Form	Standard Number	Voltage - Output	Region Utilized	Applications	Output Connector	Cord Length	Cord Length	Current - Output (Max) [Max]	Operating Temperature [Min]	Operating Temperature [Max]
FSP Technology Inc. FSP250M-KBA	250 W	150 mW	264 VAC	80 VAC	Level VI	CE, cULus, FCC, TUV, VCCI	IEC 320-C14	Cord	Desktop (Class I)	60601-1	19 V	International	Medical	Rectangular, 6 Position	36 in	0.91 m	13.16 A	-20 C	60 °C

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

19V 250 W AC/DC External Desktop (Class I) Adapter Cord (Sold Separately) Input

Technical documentation and resources
