109R0812F4011
ActiveSanyo Denki America Inc.
FAN AXIAL 80X25MM 12VDC WIRE
Deep-Dive with AI
Search across all available documentation for this part.
109R0812F4011
ActiveSanyo Denki America Inc.
FAN AXIAL 80X25MM 12VDC WIRE
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | 109R0812F4011 |
|---|---|
| Air Flow | 0.91 mł/min |
| Air Flow | 32.5 CFM |
| Approval Agency | CSA, TUV, UL |
| Bearing Type | Ball |
| Current Rating (Amps) | 110 mA |
| Fan Type | Tubeaxial |
| Features | Speed Sensor (Tach), Locked Rotor Protection |
| Material - Blade | Plastic |
| Material - Frame | Plastic |
| Noise | 26 dB |
| Operating Temperature [Max] | 70 °C |
| Operating Temperature [Max] | 70 °C |
| Operating Temperature [Min] | -20 °C |
| Operating Temperature [Min] | -20 C |
| Power (Watts) | 1.32 W |
| RPM | 2600 RPM |
| Size / Dimension [x] | 80 mm |
| Size / Dimension [y] | 80 mm |
| Static Pressure | 0.114 in H2O |
| Static Pressure | 28.4 Pa |
| Termination | 3 Wire Leads |
| Voltage - Rated | 12 VDC |
| Voltage Range [Max] | 13.8 VDC |
| Voltage Range [Min] | 6 VDC |
| Weight | 0.243 lb |
| Weight | 110.22 g |
| Width [y] | 25 mm |
109R0812 Series
| Part | Voltage Range [Max] | Voltage Range [Min] | Approval Agency | Current Rating (Amps) | Power (Watts) | Static Pressure | Static Pressure | Operating Temperature [Min] | Operating Temperature [Max] | Operating Temperature [Min] | Operating Temperature [Max] | Size / Dimension [y] | Size / Dimension [x] | Termination | Weight | Weight | Voltage - Rated | Air Flow | Air Flow | Bearing Type | Material - Blade | Fan Type | RPM | Width [y] | Material - Frame | Noise | Features | Lifetime @ Temp. |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Sanyo Denki America Inc. | 13.8 VDC | 6 VDC | CSA TUV UL | 110 mA | 1.32 W | 0.114 in H2O | 28.4 Pa | -20 °C | 70 °C | -20 C | 70 °C | 80 mm | 80 mm | 2 Wire Leads | 0.243 lb | 110.22 g | 12 VDC | 0.91 mł/min | 32.5 CFM | Ball | Plastic | Tubeaxial | 2600 RPM | 25 mm | Plastic | 26 dB | ||
Sanyo Denki America Inc. | 13.8 VDC | 6 VDC | CSA TUV UL | 110 mA | 1.32 W | 0.114 in H2O | 28.4 Pa | -20 °C | 70 °C | -20 C | 70 °C | 80 mm | 80 mm | 3 Wire Leads | 0.243 lb | 110.22 g | 12 VDC | 0.91 mł/min | 32.5 CFM | Ball | Plastic | Tubeaxial | 2600 RPM | 25 mm | Plastic | 26 dB | Locked Rotor Protection Speed Sensor (Tach) | |
Sanyo Denki America Inc. | 13.8 VDC | 6 VDC | CSA TUV UL | 110 mA | 1.32 W | 0.114 in H2O | 28.4 Pa | -20 °C | 70 °C | -20 C | 70 °C | 80 mm | 80 mm | 3 Wire Leads | 0.243 lb | 110.22 g | 12 VDC | 0.91 mł/min | 32.5 CFM | Ball | Plastic | Tubeaxial | 2600 RPM | 25 mm | Plastic | 26 dB | Locked Rotor Protection Speed Sensor (Tach) | |
Sanyo Denki America Inc. | 13.2 VDC | 10.8 VDC | CSA TUV UL | 370 mA | 4.44 W | 0.323 in H2O | 80.4 Pa | -20 °C | 60 °C | -20 C | 60 °C | 80 mm | 80 mm | 3 Wire Leads | 0.243 lb | 110.22 g | 12 VDC | 1.48 mł/min | 53 CFM | Ball | Plastic | Tubeaxial | 4500 RPM | 25 mm | Plastic | 40 dB(A) | Locked Rotor Protection Speed Sensor (Tach) | 40000 Hrs |
Sanyo Denki America Inc. | 13.8 VDC | 7 V | CSA TUV UL | 60 mA | 720 mW | 0.059 in H2O | 14.7 Pa | -20 °C | 70 °C | -20 C | 70 °C | 80 mm | 80 mm | 2 Wire Leads | 0.243 lb | 110.22 g | 12 VDC | 0.644 m³/min | 23 CFM | Ball | Plastic | Tubeaxial | 1850 RPM | 25 mm | Plastic | 20 dB | ||
Sanyo Denki America Inc. | 13.8 VDC | 6 VDC | CSA TUV UL | 1.56 W | 0.142 in H2O | 35.4 Pa | -20 °C | 70 °C | -20 C | 70 °C | 80 mm | 80 mm | 2 Wire Leads | 0.243 lb | 110.22 g | 12 VDC | 1.02 m³/min | 36.4 CFM | Ball | Plastic | Tubeaxial | 2900 RPM | 25 mm | Plastic | 29 dB(A) | |||
Sanyo Denki America Inc. | 13.8 VDC | 6 VDC | CSA TUV UL | 1.56 W | 0.142 in H2O | 35.4 Pa | -20 °C | 70 °C | -20 C | 70 °C | 80 mm | 80 mm | 2 Wire Leads | 0.243 lb | 110.22 g | 12 VDC | Ball | Plastic | Tubeaxial | 2900 RPM | 25 mm | Plastic | 29 dB(A) | |||||
Sanyo Denki America Inc. | 13.8 VDC | 6 VDC | CSA TUV UL | 0.09 A | 1.08 W | 0.09 in H2O | 22.4 Pa | -20 °C | 70 °C | -20 C | 70 °C | 80 mm | 80 mm | 2 Wire Leads | 0.243 lb | 110.22 g | 12 VDC | 0.82 m³/min | 29.3 CFM | Ball | Plastic | Tubeaxial | 2350 RPM | 25 mm | Plastic | 23 dB(A) | ||
Sanyo Denki America Inc. | 13.8 VDC | 6 VDC | CSA TUV UL | 110 mA | 1.32 W | 0.114 in H2O | 28.4 Pa | -20 °C | 70 °C | -20 C | 70 °C | 80 mm | 80 mm | 2 Wire Leads | 0.243 lb | 110.22 g | 12 VDC | 0.91 mł/min | 32.5 CFM | Ball | Plastic | Tubeaxial | 2600 RPM | 25 mm | Plastic | 26 dB | ||
Sanyo Denki America Inc. | 13.8 VDC | 6 VDC | CSA TUV UL | 0.18 A | 2.16 W | 0.193 in H2O | 48.1 Pa | -20 °C | 70 °C | -20 C | 70 °C | 80 mm | 80 mm | 3 Wire Leads | 0.243 lb | 110.22 g | 12 VDC | Ball | Plastic | Tubeaxial | 3400 RPM | 25 mm | Plastic | 34 dB(A) | Locked Rotor Sensor |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 15.67 | |
| 10 | $ 14.96 | |||
| 40 | $ 14.07 | |||
| 80 | $ 13.53 | |||
| 120 | $ 12.47 | |||
| 280 | $ 11.66 | |||
| 520 | $ 11.49 | |||
Description
General part information
109R0812 Series
Fan Tubeaxial 12VDC Square - 80mm L x 80mm H Ball 32.5 CFM (0.910m³/min) 3 Wire Leads
