CMCP310FG-48-01-00

Active

STI Vibration Monitoring

JUNCTION BOX FIBER 16"L X 14"W

Search across all available documentation for this part.

Active

STI Vibration Monitoring

JUNCTION BOX FIBER 16"L X 14"W

Technical Specifications

Parameters and characteristics commom to parts in this series

JUNCTION BOX FIBER 16"L X 14"W

Part	Container Type	Height [z]	Height [z]	Area (L x W) [x]	Area (L x W) [x]	Color	Material	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Design	Ratings	Size / Dimension	Area (L x W)	Area (L x W)
STI Vibration Monitoring CMCP310FG-48-01-00	Junction Box	10 in	254 mm	224 in˛	1445 cm˛	Gray	Fiberglass	355.6 mm	16 in	14 in	406.4 mm	Cover Included	IP66, NEMA 4X
STI Vibration Monitoring CMCP310FG-36-01-00	Junction Box	10 in	254 mm	224 in˛	1445 cm˛	Gray	Fiberglass	355.6 mm	16 in	14 in	406.4 mm	Cover Included	IP66, NEMA 4X
STI Vibration Monitoring CMCP310FG-12-01-00	Junction Box	8 "	203.2 mm			Gray	Fiberglass		12 in	10 in		Cover Included	IP66, NEMA 4X	254 mm, 304.8 mm	774 cm²	120 in²

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	1	$ 1750.00

General part information

Junction Box Fiberglass Gray Cover Included 16.000" L x 14.000" W (406.40mm x 355.60mm) X 10.000" (254.00mm)
