PVD100Q

Active

BANNER ENGINEERING

SAFETY LIGHT CURTAIN, 4, 100 MM, 2 M

Search across all available documentation for this part.

Active

BANNER ENGINEERING

SAFETY LIGHT CURTAIN, 4, 100 MM, 2 M

Technical Specifications

Parameters and characteristics for this part

Part	Light Source	Light Source	Output Configuration	Connection Method	Adjustment Type	Voltage - Supply [Min]	Voltage - Supply [Max]	Sensing Method	Response Time	Cable Length	Cable Length	Ingress Protection
BANNER ENGINEERING PVD100Q W/6IN	Red	630 nm	NPN/PNP	Cable with Connector	Adjustable	12 V	30 VDC	Diffuse Retroreflective	400 ms	78.74 in	2 m	NEMA 2 IEC IP62
BANNER ENGINEERING PVD100Q	Red	630 nm	NPN/PNP	Cable with Connector	Adjustable	12 V	30 VDC	Diffuse Retroreflective	400 ms	78.74 in	2 m	NEMA 2 IEC IP62

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	1	$ 367.00
Newark	Each	1	$ 374.00

General part information

Retroreflective, Diffuse Optical Sensor NPN/PNP
