Specification	109P0412P3B013

Air Flow	13.4 CFM
Approval Agency	CSA, TUV, UL
Bearing Type	Ball
Fan Type	Tubeaxial
Features	PWM Control, Locked Rotor Protection, Speed Sensor (Tach)
Noise	40 dB
Operating Temperature (Max)	60 °C
Operating Temperature (Min)	-20 °C
Power (Watts)	3.36 W
RPM	10300 RPM
Size / Dimension Height	40 mm
Size / Dimension Length	40 mm
Size / Dimension Shape	Square
Static Pressure	0.574 in H2O
Termination	4 Wire Leads
Termination Leads Count	4 leads
Termination Type	Wire Leads
Voltage - Rated	12 VAC
Weight	0.115 lb
Width	28 mm

9P Type Series

Part	Voltage - Rated	Noise	Termination Leads Count	Termination Type	Termination	Features	Air Flow	Operating Temperature (Min)	Operating Temperature (Max)	Width	RPM	Size / Dimension Length	Size / Dimension Shape	Size / Dimension Height	Fan Type	Power (Watts)	Weight	Approval Agency	Static Pressure	Bearing Type	Lifetime	Material - Frame	Voltage Range (Max)	Voltage Range (Min)	Current Rating	Material - Blade
Sanyo Denki America Inc. 109P0405F3D013	5 VAC	30 dB	3	Wire Leads	3 Wire Leads	Locked Rotor Sensor	8.6 CFM	-4 °F	158 °F	28 mm	6700 RPM	40 mm	Square	40 mm	Tubeaxial	1.4 W	0.115 lb	CSA TUV UL	0.236 in H2O	Ball	60000 Hrs	Plastic	5.5 VDC	4.5 VDC	0.28 A	Plastic
Sanyo Denki America Inc. 109P1312S1021	12 VAC	47 dB	2 leads	Wire Leads	2 Wire Leads	Locked Rotor Protection	148 CFM	-20 °C	60 °C	38 mm	3300 RPM	5 in	Square	5 in	Tubeaxial	15.6 W	0.772 lb	CSA TUV UL	0.472 in H2O	Ball
Sanyo Denki America Inc. 109P0624J7D01	24 VAC	44 dB	3	Wire Leads	3 Wire Leads	Locked Rotor Sensor	21.5 CFM	-20 °C	60 °C	15 mm	6200 RPM	60 mm	Square	60 mm	Tubeaxial	3.36 W	0.133 lb	CSA TUV UL	0.347 in H2O	Ball	40000 Hrs	Plastic	27.6 VDC	14 VDC	140 mA	Plastic
Sanyo Denki America Inc. 109P0424H9D01	24 VAC		3	Wire Leads	3 Wire Leads	Locked Rotor Sensor				10 mm		40 mm	Square	40 mm	Tubeaxial			CSA TUV UR		Ball		Plastic				Plastic
Sanyo Denki America Inc. 109P0512H702	12 VAC	27 dB	2 leads	Wire Leads	2 Wire Leads	Locked Rotor Protection	9 CFM	-4 °F	158 °F	15 mm	4600 RPM	52 mm	Square	52 mm	Tubeaxial	1.2 W	0.122 lb	CSA TUV UL	0.128 in H2O	Ball	60000 Hrs	Plastic	13.8 VDC	7 V	100 mA	Plastic
Sanyo Denki America Inc. 109P0412G3D01	12 VAC	42 dB	3	Wire Leads	3 Wire Leads	Locked Rotor Sensor		-20 °C	60 °C	28 mm	11500 RPM	40 mm	Square	40 mm	Tubeaxial	3.72 W	0.115 lb	CSA TUV UL		Ball
Sanyo Denki America Inc. 109P0612B701	12 VAC	21 dB	3	Wire Leads	3 Wire Leads	Locked Rotor Protection Speed Sensor (Tach)	7.4 CFM	-4 °F	158 °F	15 mm	2200 RPM	60 mm	Square	60 mm	Tubeaxial	600 mW	0.133 lb	CSA TUV UL	0.047 in H2O	Ball
Sanyo Denki America Inc. 109P0824H6D01	24 VAC	31 dB	3	Wire Leads	3 Wire Leads	Locked Rotor Sensor	29.7 CFM	-4 °F	158 °F	20 mm	2900 RPM	80 mm	Square	80 mm	Tubeaxial	2.88 W	0.222 lb	CSA TUV UL	0.118 in H2O	Ball	60000 Hrs	Plastic	27.6 VDC	20.4 VDC	120 mA	Plastic
Sanyo Denki America Inc. 109P0812M601	12 VAC	25 dB	3	Wire Leads	3 Wire Leads	Locked Rotor Protection Speed Sensor (Tach)	23.7 CFM	-4 °F	158 °F	20 mm	2300 RPM	80 mm	Square	80 mm	Tubeaxial	1.56 W	0.222 lb	CSA TUV UL	0.075 in H2O	Ball	60000 Hrs	Plastic	13.8 VDC	10.2 VDC	0.13 A	Plastic
Sanyo Denki America Inc. 109P1424H1D01	24 VAC	46 dB	3	Wire Leads	3 Wire Leads	Locked Rotor Sensor	159 CFM	-4 °F	158 °F	38 mm	2600 RPM	140 mm	Square	140 mm	Tubeaxial	8.88 W	0.993 lb	CSA TUV UL	0.378 in H2O	Ball
