PMN.2M.312.XLMT

Active

LEMO

CONN RCPT FMALE 12POS GOLD CRIMP

Search across all available documentation for this part.

Active

LEMO

CONN RCPT FMALE 12POS GOLD CRIMP

Technical Specifications

Parameters and characteristics for this part

Specification	PMN.2M.312.XLMT

Applications	Military, Aerospace, Automotive, Aviation
Cable Opening [custom]	0.512 in
Cable Opening [custom]	13 mm
Color	Gray
Connector Type	Receptacle, Female Sockets
Contact Finish - Mating	Gold
Contact Finish Thickness - Mating	59 Áin
Contact Finish Thickness - Mating	1.5 Ám
Contact Material	Bronze
Current Rating (Amps)	7 A
Ingress Protection	IP68 - Dust Tight, Waterproof
Insert Material	Polyetheretherketone (PEEK)
Mounting Type	Free Hanging (In-Line)
Number of Positions	12
Operating Temperature [Max]	200 °C
Operating Temperature [Min]	-55 °C
Orientation	N
Primary Material	Metal
Shell Finish	Nickel
Shell Material	Aluminum Alloy
Shell Size - Insert	312
Shielding	Shielded
Termination	Crimp

CONN RCPT FMALE 12POS GOLD CRIMP

Part	Orientation	Primary Material	Shell Finish	Contact Finish - Mating	Shielding	Termination	Insert Material	Current Rating (Amps)	Applications	Shell Material	Cable Opening [custom]	Cable Opening [custom]	Shell Size - Insert	Contact Material	Connector Type	Mounting Type	Ingress Protection	Color	Operating Temperature [Min]	Operating Temperature [Max]	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Number of Positions
LEMO PMN.2M.312.XLMT	N	Metal	Nickel	Gold	Shielded	Crimp	Polyetheretherketone (PEEK)	7 A	Aerospace, Automotive, Aviation, Military	Aluminum Alloy	0.512 in	13 mm	312	Bronze	Receptacle, Female Sockets	Free Hanging (In-Line)	IP68 - Dust Tight, Waterproof	Gray	-55 °C	200 °C	59 Áin	1.5 Ám	12

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

12 Position Circular Connector Receptacle, Female Sockets Crimp
