Specification	TR9CE13330YL4IMR6B

Applications	Medical, ITE (Commercial), Household Appliances
Approval Agency	cETLus, EAC, ETL, S-Mark, PSE, VCCI, UKRSepro, CCC, CB, RCM, CE
Cord Length	39.4 in
Current - Output (Max)	13.33 A
Efficiency	Level VI, CoC Tier 2
Form	Desktop (Class I)
Input Connector	IEC 320-C14
Input Type	Cord (Sold Separately)
No Load Power Consumption (Max)	150 mW
Operating Temperature (Max)	40 °C
Operating Temperature (Min)	-10 °C
Output Connector	4 Pin, Power DIN
Power (Watts)	160 W
Region Utilized	International
Size / Dimension Height	1.58 in
Size / Dimension Length	6.95 in
Size / Dimension Width	2.91 in
Standard Number	62368-1, 60950-1, 60601-1-11, 60335-1, 60601-1-2
Voltage - Input (AC) Maximum	264 V
Voltage - Input (AC) Minimum	90 V
Voltage - Output	12 V

TR9CE13330 Series

Part	Input Type	Voltage - Output	Output Connector	Region Utilized	Applications	Voltage - Input (AC) Minimum	Voltage - Input (AC) Maximum	Efficiency	Operating Temperature (Min)	Operating Temperature (Max)	No Load Power Consumption (Max)	Form	Input Connector	Cord Length	Approval Agency	Power (Watts)	Current - Output (Max)	Size / Dimension Width	Size / Dimension Height	Size / Dimension Length	Standard Number
GlobTek, Inc. TR9CE13330YL4IMR6B	Cord (Sold Separately)	12 V	4 Pin Power DIN	International	Household Appliances ITE (Commercial) Medical	90 V	264 V	CoC Tier 2 Level VI	-10 °C	40 °C	150 mW	Desktop (Class I)	IEC 320-C14	39.4 in	CB CCC CE cETLus EAC ETL PSE RCM S-Mark UKRSepro VCCI	160 W	13.33 A	2.91 in	1.58 in	6.95 in	60335-1 60601-1-11 60601-1-2 60950-1 62368-1
GlobTek, Inc. TR9CE13330A04CIMR6B	Cord (Sold Separately)	12 V	Stripped Tinned Wire Leads	International	Household Appliances ITE (Commercial) Medical	90 V	264 V	CoC Tier 2 Level VI	-10 °C	40 °C	150 mW	Desktop (Class I)	IEC 320-C14	11.8 in	CB CCC CE cETLus EAC ETL PSE RCM S-Mark UKRSepro VCCI	160 W	13.33 A	2.91 in	1.58 in	6.93 in
GlobTek, Inc. TR9CE13330YL4IMCFR6B	Cord (Sold Separately)	12 V	4 Pin Power DIN	International	Household Appliances ITE (Commercial) Medical	90 V	264 V	CoC Tier 1 Level VI	-10 °C	40 °C	150 mW	Desktop (Class I)	IEC 320-C14	39.4 in	CB CCC CE cETLus EAC ETL PSE RCM S-Mark UKRSepro VCCI	160 W	13.33 A	2.91 in	1.58 in	6.93 in	60335-1 60601-1 60950-1 62368-1
