Specification	405F/2H

Air Flow	5.3 CFM
Approval Agency	VDE, CSA, UL
Bearing Type	Sintec
Fan Type	Tubeaxial
Features	Speed Sensor (Tach)
Material - Blade	Nylon, Polyamide, PA, Fiberglass Reinforced
Material - Frame	Fiberglass Reinforced, Polybutylene Terephthalate (PBT)
Noise	26 dB
Power (Watts)	900 mW
RPM	6000 RPM
Size / Dimension Height	40 mm
Size / Dimension Length	40 mm
Size / Dimension Shape	Square
Termination	3 Wire Leads
Termination Leads Count	3
Termination Type	Wire Leads
Voltage - Rated	5 VAC
Weight	0.038 lb
Width	10 mm

405F Series

Part	Material - Frame	Material - Blade	Fan Type	Bearing Type	Voltage - Rated	Approval Agency	Features	Air Flow	Width	Weight	Power (Watts)	RPM	Termination Leads Count	Termination Type	Termination	Noise	Size / Dimension Length	Size / Dimension Shape	Size / Dimension Height
ebm-papst Inc. 405F/2H	Fiberglass Reinforced Polybutylene Terephthalate (PBT)	Fiberglass Reinforced Nylon PA Polyamide	Tubeaxial	Sintec	5 VAC	CSA UL VDE	Speed Sensor (Tach)	5.3 CFM	10 mm	0.038 lb	900 mW	6000 RPM	3	Wire Leads	3 Wire Leads	26 dB	40 mm	Square	40 mm
