Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Spool | 1000 | $ 0.55 | |
General part information
8 (4 Pair Twisted) Conductor Multi-Pair, Cat5e Cable Gray 24 AWG 1000.0' (304.8m)
Technical documentation and resources
Parameters and characteristics commom to parts in this series
| Specification | 1213 008U1000 | 1213 Series |
|---|---|---|
| Cable Type | Multi-Pair, Cat5e | Multi-Pair, Cat5e |
| Conductor Insulation | Fluorinated Ethylene-Propylene (FEP), Polyolefin (PO) | Fluorinated Ethylene-Propylene (FEP), Polyolefin (PO) |
| Conductor Material | Copper, Bare | Copper, Bare |
| Conductor Strand | Solid | Solid |
| Features | Rip Cord, Flame Retardant | Rip Cord, Flame Retardant |
| Jacket (Insulation) Diameter | 0.207 in | 0.207 in |
| Jacket (Insulation) Diameter | 5.26 mm | 5.26 mm |
| Jacket (Insulation) Material | Low Smoke Poly-Vinyl Chloride (LSPVC), Plenum | Low Smoke Poly-Vinyl Chloride (LSPVC), Plenum |
| Jacket Color | Gray | Gray, Pink, Yellow, Orange |
| Length | 1000 ft | 1000 ft |
| Length | 304.8 m | 304.8 m |
| Number of Conductors | 8 | 8 |
| Ratings | UL Style CMP | UL Style CMP |
| Usage | Video, Ethernet, LAN | Video, Ethernet, LAN |
| Voltage | 300 V | 300 V |
| Wire Gauge | 24 AWG | 24 AWG |
CABLE CAT5E 8CON 24AWG GRY
| Part | Cable Type | Jacket (Insulation) Material | Usage | Features | Voltage | Jacket Color | Wire Gauge | Conductor Material | Conductor Insulation | Length | Length | Jacket (Insulation) Diameter | Jacket (Insulation) Diameter | Number of Conductors | Ratings | Conductor Strand |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Belden Inc. 1213 008U1000 | Multi-Pair, Cat5e | Low Smoke Poly-Vinyl Chloride (LSPVC), Plenum | Ethernet, LAN, Video | Flame Retardant, Rip Cord | 300 V | Gray | 24 AWG | Copper, Bare | Fluorinated Ethylene-Propylene (FEP), Polyolefin (PO) | 1000 ft | 304.8 m | 0.207 in | 5.26 mm | 8 | UL Style CMP | Solid |
Belden Inc. 1213 0091000 | Multi-Pair, Cat5e | Low Smoke Poly-Vinyl Chloride (LSPVC), Plenum | Ethernet, LAN, Video | Flame Retardant, Rip Cord | 300 V | 24 AWG | Copper, Bare | Fluorinated Ethylene-Propylene (FEP), Polyolefin (PO) | 1000 ft | 304.8 m | 0.207 in | 5.26 mm | 8 | UL Style CMP | Solid | |
Belden Inc. 1213 012U1000 | Multi-Pair, Cat5e | Low Smoke Poly-Vinyl Chloride (LSPVC), Plenum | Ethernet, LAN, Video | Flame Retardant, Rip Cord | 300 V | Pink | 24 AWG | Copper, Bare | Fluorinated Ethylene-Propylene (FEP), Polyolefin (PO) | 1000 ft | 304.8 m | 0.207 in | 5.26 mm | 8 | UL Style CMP | Solid |
Belden Inc. 1213 004U1000 | Multi-Pair, Cat5e | Low Smoke Poly-Vinyl Chloride (LSPVC), Plenum | Ethernet, LAN, Video | Flame Retardant, Rip Cord | 300 V | Yellow | 24 AWG | Copper, Bare | Fluorinated Ethylene-Propylene (FEP), Polyolefin (PO) | 1000 ft | 304.8 m | 0.207 in | 5.26 mm | 8 | UL Style CMP | Solid |
Belden Inc. 1213 003U1000 | Multi-Pair, Cat5e | Low Smoke Poly-Vinyl Chloride (LSPVC), Plenum | Ethernet, LAN, Video | Flame Retardant, Rip Cord | 300 V | Orange | 24 AWG | Copper, Bare | Fluorinated Ethylene-Propylene (FEP), Polyolefin (PO) | 1000 ft | 304.8 m | 0.207 in | 5.26 mm | 8 | UL Style CMP | Solid |
