AEE00CC48-M

Obsolete

ARTESYN / Advanced Energy

DC DC CONVERTER +/-15V 10W

Search across all available documentation for this part.

Obsolete

ARTESYN / Advanced Energy

DC DC CONVERTER +/-15V 10W

Technical Specifications

Parameters and characteristics for this part

Part	Voltage - Output 1	Package / Case	Voltage - Input (Min) [Min]	Power (Watts)	Type	Mounting Type	Applications	Current - Output (Max)	Current - Output (Max)	Number of Outputs	Operating Temperature [Max]	Operating Temperature [Min]	Voltage - Isolation	Features	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]	Voltage - Output 2	Voltage - Input (Max) [Max]	Efficiency	Current - Output (Max)
ARTESYN / Advanced Energy AEE00CC48-M	15 V	5-DIP Module	36 V	10 W	Isolated Module	Through Hole	ITE (Commercial) Medical	333 mA	333 mA	2	85 °C	-40 °C	4.2 kV	OCP OTP OVP SCP	25.4 mm	50.8 mm	0.47 "	11.8 mm	25.4 mm	2 in	-15 V	75 V
ARTESYN / Advanced Energy AEE00CC36-LS	15 V	5-DIP Module	18 V	15 W	Isolated Module	Through Hole	ITE (Commercial)		500 mA	2	71 °C	-40 °C	1.5 kV	SCP	25.4 mm	50.8 mm	0.44 "	11.3 mm	25.4 mm	2 in	-15 V	75 V	84 %	500 mA
ARTESYN / Advanced Energy AEE00CC18-LS	15 V	5-DIP Module	9 V	15 W	Isolated Module	Through Hole	ITE (Commercial)		500 mA	2	71 °C	-40 °C	1.5 kV	SCP	25.4 mm	50.8 mm	0.44 "	11.3 mm	25.4 mm	2 in	-15 V	36 V	84 %	500 mA

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

Isolated Module DC DC Converter 2 Output 15V -15V 333mA, 333mA 36V - 75V Input

Technical documentation and resources

No documents available
