Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1000 | $ 0.44 | |
| Tube | 250 | $ 2.33 | ||
| 500 | $ 1.44 | |||
| 1000 | $ 0.98 | |||
| 2000 | $ 0.97 | |||
General part information
Diode Array 1 Pair Common Cathode 100 V 10A Surface Mount TO-263-3, D2PAK (2 Leads + Tab), TO-263AB
Technical documentation and resources
Parameters and characteristics for this part
| Specification | SK20100CD2 |
|---|---|
| Current - Average Rectified (Io) (per Diode) | 10 A |
| Current - Reverse Leakage @ Vr | 200 µA |
| Diode Configuration | 1 Pair Common Cathode |
| Mounting Type | Surface Mount |
| Operating Temperature - Junction [Max] | 150 °C |
| Operating Temperature - Junction [Min] | -50 °C |
| Package / Case | D2PAK (2 Leads + Tab), TO-263AB, TO-263-3 |
| Speed | 200 mA, 500 ns |
| Supplier Device Package | TO-263AB (D2PAK) |
| Technology | Schottky |
| Voltage - DC Reverse (Vr) (Max) [Max] | 100 V |
| Voltage - Forward (Vf) (Max) @ If [Max] | 850 mV |
DIODE ARR SCHOT 100V 10A TO263AB
| Part | Supplier Device Package | Voltage - DC Reverse (Vr) (Max) [Max] | Technology | Current - Reverse Leakage @ Vr | Voltage - Forward (Vf) (Max) @ If [Max] | Speed | Operating Temperature - Junction [Min] | Operating Temperature - Junction [Max] | Current - Average Rectified (Io) (per Diode) | Package / Case | Mounting Type | Diode Configuration |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
Diotec Semiconductor SK20100CD2 | TO-263AB (D2PAK) | 100 V | Schottky | 200 µA | 850 mV | 200 mA, 500 ns | -50 °C | 150 °C | 10 A | D2PAK (2 Leads + Tab), TO-263-3, TO-263AB | Surface Mount | 1 Pair Common Cathode |
