Specification	R150A1-051-D0760

Air Flow	365 CFM
Bearing Type	Ball
Current Rating	1.5 A
Fan Type	Tubeaxial
Features	PWM Control, Speed Sensor (Tach)
Lifetime	70000 Hrs
Material - Blade	Plastic
Material - Frame	Aluminum
Noise	73 dB
Operating Temperature (Max)	158 °F
Operating Temperature (Min)	-22 °F
Power (Watts)	72 W
RPM	6300 RPM
Size / Dimension Height	150 mm
Size / Dimension Length	172.7 mm
Size / Dimension Shape	Rectangular/Rounded
Static Pressure	3.485 in H2O
Termination	4 Wire Leads
Termination Leads Count	4 leads
Termination Type	Wire Leads
Voltage - Rated	48 VDC
Voltage Range (Max)	72 VDC
Voltage Range (Min)	30 VDC
Weight	2.3 lbs
Width	50 mm

R150A1 Series

Part	Static Pressure	Power (Watts)	Bearing Type	Width	Noise	Size / Dimension Length	Size / Dimension Shape	Size / Dimension Height	Air Flow	Voltage - Rated	Termination Leads Count	Termination Type	Termination	Operating Temperature (Max)	Operating Temperature (Min)	Fan Type	Weight	Features	RPM	Voltage Range (Max)	Voltage Range (Min)	Lifetime	Material - Blade	Current Rating	Material - Frame
NMB TECHNOLOGIES R150A1-051-D0760	3.485 in H2O	72 W	Ball	50 mm	73 dB	172.7 mm	Rectangular/Rounded	150 mm	365 CFM	48 VDC	4 leads	Wire Leads	4 Wire Leads	158 °F	-22 °F	Tubeaxial	2.3 lbs	PWM Control Speed Sensor (Tach)	6300 RPM	72 VDC	30 VDC	70000 Hrs	Plastic	1.5 A	Aluminum
