ZUS32415-G

Obsolete

Cosel USA, Inc.

DC DC CONVERTER 15V 3W

Search across all available documentation for this part.

Obsolete

Cosel USA, Inc.

DC DC CONVERTER 15V 3W

Technical Specifications

Parameters and characteristics for this part

DC DC CONVERTER 15V 3W

Part	Type	Voltage - Isolation	Mounting Type	Power (Watts)	Voltage - Input (Max) [Max]	Applications	Efficiency	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Package / Case	Current - Output (Max) [Max]	Operating Temperature [Min]	Operating Temperature [Max]	Number of Outputs	Voltage - Output 1	Voltage - Input (Min) [Min]
Cosel USA, Inc. ZUS32415-G	Isolated Module	500 V	Through Hole	3 W	36 V	ITE (Commercial)	75 %	0.28 "	1.38 "	0.91 in	35 mm	7 mm	23 mm	4-DIP Module	200 mA	-20 °C	71 °C	1	15 V	18 V

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

Isolated Module DC DC Converter 1 Output 15V 200mA 18V - 36V Input
