ADJ41012

Active

Panasonic Electric Works

RELAY GEN PURPOSE DPST 10A 12V

Search across all available documentation for this part.

Active

Panasonic Electric Works

RELAY GEN PURPOSE DPST 10A 12V

Technical Specifications

Parameters and characteristics for this part

Specification	ADJ41012

Approval Agency	CQC, VDE, cURus
Coil Resistance	960 Ohms
Coil Type	Latching, Single Coil
Coil Voltage	12 VDC
Contact Form	DPST-NO/NC
Contact Material	Gold (Au), Silver Tin Oxide (AgSnO)
Contact Rating (Current)	10 A
Load - Max Switching [Max]	2500 VA
Mounting Type	Through Hole
Must Operate Voltage	8.4 VDC
Operate Time	20 ms
Operating Temperature [Max]	70 °C
Operating Temperature [Min]	-40 °C
Relay Type	General Purpose
Release Time	20 ms
Seal Rating	Sealed - Flux Protection
Switching Voltage	250 VAC
Termination Style	PC Pin

Part	Switching Voltage	Load - Max Switching [Max]	Seal Rating	Operating Temperature [Min]	Operating Temperature [Max]	Must Operate Voltage	Termination Style	Contact Material	Relay Type	Coil Type	Coil Voltage	Coil Resistance	Contact Form	Release Time	Approval Agency	Contact Rating (Current)	Mounting Type	Operate Time	Coil Current
Panasonic Electric Works ADJ41012	250 VAC	2500 VA	Sealed - Flux Protection	-40 °C	70 °C	8.4 VDC	PC Pin	Gold (Au) Silver Tin Oxide (AgSnO)	General Purpose	Latching Single Coil	12 VDC	960 Ohms	DPST-NO/NC	20 ms	CQC cURus VDE	10 A	Through Hole	20 ms
Panasonic Electric Works ADJ41048	250 VAC	2500 VA	Sealed - Flux Protection	-40 °C	70 °C	33.6 VDC	PC Pin	Gold (Au) Silver Tin Oxide (AgSnO)	General Purpose	Latching Single Coil	48 VDC	15.36 kOhms	DPST-NO/NC	20 ms	CQC cURus VDE	10 A	Through Hole	20 ms	3.1 mA
Panasonic Electric Works ADJ41006	250 VAC	2500 VA	Sealed - Flux Protection	-40 °C	70 °C	4.2 VDC	PC Pin	Gold (Au) Silver Tin Oxide (AgSnO)	General Purpose	Latching Single Coil		240 Ohms	DPST-NO/NC	20 ms	CQC cURus VDE	10 A	Through Hole	20 ms
Panasonic Electric Works ADJ41024	250 VAC	2500 VA	Sealed - Flux Protection	-40 °C	70 °C	16.8 VDC	PC Pin	Gold (Au) Silver Tin Oxide (AgSnO)	General Purpose	Latching Single Coil	24 VDC	3.84 kOhms	DPST-NO/NC	20 ms	CQC cURus VDE	10 A	Through Hole	20 ms	6.3 mA

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	100	$ 15.45

General part information

General Purpose Relay DPST-NO/NC (1 Form A, 1 Form B) 12VDC Coil Through Hole
