MT323012

Obsolete

TE Connectivity Potter & Brumfield Relays

RELAY GEN PURPOSE 3PDT 10A 12V

Search across all available documentation for this part.

Obsolete

TE Connectivity Potter & Brumfield Relays

RELAY GEN PURPOSE 3PDT 10A 12V

Technical Specifications

Parameters and characteristics for this part

Specification	MT323012

Approval Agency	cURus, VDE
Coil Current	109 mA
Coil Insulation	Class B
Coil Resistance	110 Ohms
Coil Type	Non Latching
Coil Voltage	12 VDC
Contact Form	3PDT (3 Form C)
Contact Material	Silver Nickel (AgNi)
Contact Rating (Current)	10 A
Features	Test Button, Lighted Indicator
Load - Max Switching [Max]	2500 VA
Mounting Type	Socketable
Must Operate Voltage	9 VDC
Must Release Voltage	1.2 VDC
Operate Time	15 ms
Operating Temperature [Max]	60 °C
Operating Temperature [Min]	-40 °C
Relay Type	General Purpose
Release Time	10 ms
Switching Voltage [Max]	400 VAC
Termination Style	Plug In, 11 Pin (Octal)

Part	Operating Temperature [Min]	Operating Temperature [Max]	Contact Form	Load - Max Switching [Max]	Coil Insulation	Coil Current	Coil Voltage	Termination Style	Release Time	Switching Voltage [Max]	Operate Time	Must Release Voltage	Approval Agency	Relay Type	Must Operate Voltage	Contact Rating (Current)	Coil Type	Mounting Type	Coil Resistance	Contact Material	Features
TE Connectivity Potter & Brumfield Relays MT323012	-40 °C	60 °C	3PDT (3 Form C)	2500 VA	Class B	109 mA	12 VDC	Plug In 11 Pin (Octal)	10 ms	400 VAC	15 ms	1.2 VDC	cURus VDE	General Purpose	9 VDC	10 A	Non Latching	Socketable	110 Ohms	Silver Nickel (AgNi)	Lighted Indicator Test Button

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

General Purpose Relay 3PDT (3 Form C) 12VDC Coil Socketable
