ESS106M035AC2EA

Active

KEMET

ELEC CAP, 10UF, 35V, RADIAL LEADED ROHS COMPLIANT: YES

Search across all available documentation for this part.

Active

KEMET

ELEC CAP, 10UF, 35V, RADIAL LEADED ROHS COMPLIANT: YES

Technical Specifications

Parameters and characteristics for this part

Specification	ESS106M035AC2EA

Applications	General Purpose
Capacitance	10 µF
Height - Seated (Max) [Max] [z]	0.335 in
Height - Seated (Max) [Max] [z]	8.5 mm
Lead Spacing	2 mm
Lead Spacing	0.079 in
Lifetime @ Temp.	1000 Hrs
Mounting Type	Through Hole
Operating Temperature [Max]	105 ░C
Operating Temperature [Min]	-40 °C
Package / Case	Radial, Can
Polarization	Polar
Ripple Current @ High Frequency	54 mA
Ripple Current @ Low Frequency	36 mA
Size / Dimension [diameter]	5 mm
Size / Dimension [diameter]	0.197 "
Tolerance	20 %
Voltage - Rated	35 V

Part	Package / Case	Lifetime @ Temp.	Operating Temperature [Min]	Operating Temperature [Max]	Applications	Ripple Current @ High Frequency	Lead Spacing	Lead Spacing	Size / Dimension [diameter]	Size / Dimension [diameter]	Tolerance	Voltage - Rated	Polarization	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Ripple Current @ Low Frequency	Capacitance	Mounting Type
KEMET ESS106M025AB2AA	Radial Can	1000 Hrs	-40 °C	105 ░C	General Purpose	49.5 mA	0.059 in	1.5 mm	4 mm	0.157 in	20 %	25 VDC	Polar	0.335 in	8.5 mm	33 mA	10 µF	Through Hole
KEMET ESS106M035AC2EA	Radial Can	1000 Hrs	-40 °C	105 ░C	General Purpose	54 mA	0.079 in	2 mm	5 mm	0.197 "	20 %	35 V	Polar	0.335 in	8.5 mm	36 mA	10 µF	Through Hole

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

10 µF 35 V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 105°C
