TMC5272-EVAL-KIT
ActiveAnalog Devices Inc./Maxim Integrated
EVAL BOARD FOR TMC5272
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
TMC5272-EVAL-KIT
ActiveAnalog Devices Inc./Maxim Integrated
EVAL BOARD FOR TMC5272
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | TMC5272-EVAL-KIT | TMC5272 Series |
|---|---|---|
| Applications | - | General Purpose |
| Contents | Board(s) | Board(s) |
| Current - Output | - | 800 mA |
| Embedded | MCU, 32-Bit | MCU, 32-Bit |
| Embedded | True | False, True |
| Function | - | Driver - Fully Integrated, Control and Power Stage |
| Motor Type - Stepper | - | Bipolar |
| Mounting Type | - | Surface Mount |
| Operating Temperature | - | 125 °C |
| Operating Temperature | - | -40 °C |
| Output Configuration | - | Half Bridge (4) |
| Package / Case | - | 36-WFBGA, WLBGA |
| Primary Attributes | Motors (Stepper) | Motors (Stepper) |
| Secondary Attributes | SPI/UART Interface(s) | On-Board LEDs, SPI/UART Interface(s) |
| Supplied Contents | Board(s) | Board(s) |
| Supplier Device Package | - | 36-WLP |
| Supplier Device Package | - | 2.97 |
| Supplier Device Package | - | 3.13 |
| Technology | - | Power MOSFET |
| Type | Power Management | Power Management |
| Utilized IC / Part | TMC5272 | TMC5272 |
| Voltage - Load | - | 20 V |
| Voltage - Load | - | 2.1 V |
| Voltage - Supply | - | 2.1 V |
| Voltage - Supply | - | 20 V |
