SO96-5-00

Active

TE Connectivity Aerospace, Defense and Marine

SLDR SLEEVE WIRE-WIRE 0.275/0.3"

Search across all available documentation for this part.

Active

TE Connectivity Aerospace, Defense and Marine

SLDR SLEEVE WIRE-WIRE 0.275/0.3"

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	SO96-5-00	SO96-5 Series

Color	Transparent - Blue	Transparent - Blue
Diameter	7.62 mm, 6.99 mm	6.99 - 7.62 mm
Diameter	0.3 ", 0.275 "	0.275 - 0.3 "
Features	Immersion Resistant	Immersion Resistant, Pre-Installed Lead Wire
Length	19.05 mm	19.05 mm
Length	0.75 in	0.75 in
Type	Wire to Wire	Wire to Wire

SLDR SLEEVE WIRE-WIRE 0.275/0.3"

Part	Length	Length	Type	Features	Diameter	Diameter	Color
TE Connectivity Aerospace, Defense and Marine SO96-5-55-22-90	19.05 mm	0.75 in	Wire to Wire	Immersion Resistant, Pre-Installed Lead Wire	6.99 mm, 7.62 mm	0.275 ", 0.3 "	Transparent - Blue
TE Connectivity Aerospace, Defense and Marine SO96-5-00	19.05 mm	0.75 in	Wire to Wire	Immersion Resistant	6.99 mm, 7.62 mm	0.275 ", 0.3 "	Transparent - Blue

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Wire to Wire Solder Sleeve Transparent - Blue 0.275" (6.99mm), 0.300" (7.62mm)
