SPC5553MVR132

Obsolete

Freescale Semiconductor - NXP

IC MCU 32BIT 1.5KB FLASH 416PBGA

Search across all available documentation for this part.

Obsolete

Freescale Semiconductor - NXP

IC MCU 32BIT 1.5KB FLASH 416PBGA

Technical Specifications

Parameters and characteristics for this part

Specification	SPC5553MVR132

Connectivity	CANbus, EBI/EMI, SCI, SPI, Ethernet
Core Size	32-Bit Single-Core
Data Converters	12 b, 40 x
Mounting Type	Surface Mount
Number of I/O	220
Operating Temperature [Max]	125 °C
Operating Temperature [Min]	-40 °C
Oscillator Type	External
Package / Case	416-BBGA
Peripherals	WDT, DMA, PWM, POR
Program Memory Size	1.5 KB
Program Memory Type	FLASH
RAM Size	64 K
Speed	132 MHz
Supplier Device Package	416-PBGA (27x27)

Part	Connectivity	RAM Size	Core Size	Mounting Type	Supplier Device Package	Program Memory Type	Number of I/O	Data Converters	Package / Case	Speed	Oscillator Type	Peripherals	Program Memory Size	Operating Temperature [Max]	Operating Temperature [Min]
Freescale Semiconductor - NXP SPC5553MVR132	CANbus EBI/EMI Ethernet SCI SPI	64 K	32-Bit Single-Core	Surface Mount	416-PBGA (27x27)	FLASH	220	12 b 40 x	416-BBGA	132 MHz	External	DMA POR PWM WDT	1.5 KB	125 °C	-40 °C

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tray	9	$ 36.60

General part information

e200z6 MPC55xx Qorivva Microcontroller IC 32-Bit Single-Core 132MHz 1.5KB (1.5K x 8) FLASH 416-PBGA (27x27)

Technical documentation and resources

No documents available
