310-93-164-41-105000

Active

Mill-Max Manufacturing Corp.

CONN RCPT 64POS 0.1 GOLD SMD

Deep-Dive with AI

Search across all available documentation for this part.

310-93-164-41-105000

Active

Mill-Max Manufacturing Corp.

CONN RCPT 64POS 0.1 GOLD SMD

Deep-Dive with AI

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	310-93-164-41-105000

Connector Type	Receptacle
Contact Finish - Mating	Gold
Contact Finish - Post	Tin-Lead
Contact Finish Thickness - Mating	30 Áin
Contact Finish Thickness - Mating	0.76 Ám
Contact Finish Thickness - Post	200 µin
Contact Finish Thickness - Post	5.08 µm
Contact Material	Beryllium Copper
Contact Shape	Circular
Contact Type	Female Socket
Current Rating (Amps)	3 A
Fastening Type	Push-Pull
Insulation Color	Black
Insulation Height	5.6 mm
Insulation Height	0.22 in
Insulation Material	Polycyclohexylenedimethylene Terephthalate (PCT), Polyester
Material Flammability Rating	UL94 V-0
Mounting Type	Surface Mount
Number of Positions	64
Number of Positions Loaded	All
Number of Rows	1
Operating Temperature [Max]	125 °C
Operating Temperature [Min]	-55 °C
Pitch - Mating	0.1 in
Pitch - Mating	2.54 mm
Termination	Solder
Voltage Rating	100 V, 150 VDC

310-93 Series

...

Part	Contact Finish - Mating	Contact Length - Post [x]	Contact Length - Post [x]	Termination	Number of Positions	Insulation Color	Voltage Rating	Number of Rows	Contact Shape	Mounting Type	Material Flammability Rating	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Operating Temperature [Min]	Operating Temperature [Max]	Connector Type	Contact Finish - Post	Pitch - Mating	Pitch - Mating	Insulation Material	Fastening Type	Contact Type	Contact Material	Number of Positions Loaded	Current Rating (Amps)	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Insulation Height	Insulation Height
Mill-Max Manufacturing Corp. 310-93-136-41-001000	Gold	3.18 mm	0.125 in	Solder	36	Black	100 V 150 VDC	1	Circular	Through Hole	UL94 V-0	30 Áin	0.76 Ám	-55 °C	125 °C	Receptacle	Tin-Lead	0.1 in	2.54 mm	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Push-Pull	Female Socket	Beryllium Copper	All	3 A	200 µin	5.08 µm
Mill-Max Manufacturing Corp. 310-93-114-61-001000	Gold	3.18 mm	0.125 in	Solder	14	Black	100 V 150 VDC	1	Circular	Through Hole	UL94 V-0	30 Áin	0.76 Ám	-55 °C	125 °C	Receptacle	Tin-Lead	0.1 in	2.54 mm	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Push-Pull	Female Socket	Beryllium Copper	All	3 A	200 µin	5.08 µm
Mill-Max Manufacturing Corp. 310-93-120-61-001000	Gold	3.18 mm	0.125 in	Solder	20	Black	100 V 150 VDC	1	Circular	Through Hole	UL94 V-0	30 Áin	0.76 Ám	-55 °C	125 °C	Receptacle	Tin-Lead	0.1 in	2.54 mm	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Push-Pull	Female Socket	Beryllium Copper	All	3 A	200 µin	5.08 µm
Mill-Max Manufacturing Corp. 310-93-133-61-001000	Gold	3.18 mm	0.125 in	Solder	33	Black	100 V 150 VDC	1	Circular	Through Hole	UL94 V-0	30 Áin	0.76 Ám	-55 °C	125 °C	Receptacle	Tin-Lead	0.1 in	2.54 mm	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Push-Pull	Female Socket	Beryllium Copper	All	3 A	200 µin	5.08 µm
Mill-Max Manufacturing Corp. 310-93-122-41-001000	Gold	3.18 mm	0.125 in	Solder	22 positions	Black	100 V 150 VDC	1	Circular	Through Hole	UL94 V-0	30 Áin	0.76 Ám	-55 °C	125 °C	Receptacle	Tin-Lead	0.1 in	2.54 mm	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Push-Pull	Female Socket	Beryllium Copper	All	3 A	200 µin	5.08 µm
Mill-Max Manufacturing Corp. 310-93-138-61-001000	Gold	3.18 mm	0.125 in	Solder	38	Black	100 V 150 VDC	1	Circular	Through Hole	UL94 V-0	30 Áin	0.76 Ám	-55 °C	125 °C	Receptacle	Tin-Lead	0.1 in	2.54 mm	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Push-Pull	Female Socket	Beryllium Copper	All	3 A	200 µin	5.08 µm
Mill-Max Manufacturing Corp. 310-93-112-41-001000	Gold	3.18 mm	0.125 in	Solder	12	Black	100 V 150 VDC	1	Circular	Through Hole	UL94 V-0	30 Áin	0.76 Ám	-55 °C	125 °C	Receptacle	Tin-Lead	0.1 in	2.54 mm	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Push-Pull	Female Socket	Beryllium Copper	All	3 A	200 µin	5.08 µm
Mill-Max Manufacturing Corp. 310-93-164-41-105000	Gold			Solder	64	Black	100 V 150 VDC	1	Circular	Surface Mount	UL94 V-0	30 Áin	0.76 Ám	-55 °C	125 °C	Receptacle	Tin-Lead	0.1 in	2.54 mm	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Push-Pull	Female Socket	Beryllium Copper	All	3 A	200 µin	5.08 µm	5.6 mm	0.22 in
Mill-Max Manufacturing Corp. 310-93-136-41-105000	Gold			Solder	36	Black	100 V 150 VDC	1	Circular	Surface Mount	UL94 V-0	30 Áin	0.76 Ám	-55 °C	125 °C	Receptacle	Tin-Lead	0.1 in	2.54 mm	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Push-Pull	Female Socket	Beryllium Copper	All	3 A	200 µin	5.08 µm	5.6 mm	0.22 in
Mill-Max Manufacturing Corp. 310-93-106-61-001000	Gold	3.18 mm	0.125 in	Solder	6	Black	100 V 150 VDC	1	Circular	Through Hole	UL94 V-0	30 Áin	0.76 Ám	-55 °C	125 °C	Receptacle	Tin-Lead	0.1 in	2.54 mm	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Push-Pull	Female Socket	Beryllium Copper	All	3 A	200 µin	5.08 µm

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tube	1	$ 14.34
		12	$ 12.71
		102	$ 11.08
		501	$ 9.45
		1002	$ 8.67

Description

General part information

310-93 Series

64 Position Receptacle Connector 0.100" (2.54mm) Surface Mount Gold
