PZC30SACN

Obsolete

Sullins Connector Solutions

CONN HEADER VERT 30POS 2.54MM

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

PZC30SACN

Obsolete

Sullins Connector Solutions

CONN HEADER VERT 30POS 2.54MM

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	PZC30SACN

Connector Type	Header
Contact Finish - Mating	Gold
Contact Finish - Post	Tin
Contact Finish Thickness - Mating	10 çin
Contact Finish Thickness - Mating	0.25 çm
Contact Finish Thickness - Post	2.54 µm
Contact Finish Thickness - Post	100 µin
Contact Length - Mating	5.84 mm
Contact Length - Mating [x]	0.23 in
Contact Length - Post [x]	0.32 in
Contact Length - Post [x]	8.13 mm
Contact Material	Copper Alloy
Contact Shape	Square
Contact Type	Male Pin
Current Rating (Amps)	3 A
Fastening Type	Push-Pull
Insulation Color	Black
Insulation Height	0.1 in
Insulation Height	2.54 mm
Insulation Material	Polyester, Thermoplastic
Material Flammability Rating	UL94 V-0
Mounting Type	Through Hole
Number of Positions	30
Number of Positions Loaded	All
Number of Rows	1
Overall Contact Length	16.51 mm
Overall Contact Length	0.65 in
Pitch - Mating	0.1 in
Pitch - Mating	2.54 mm
Shrouding	Unshrouded
Style	Board to Board, Cable
Termination	Solder

PZC30 Series

Part	Mounting Type	Termination	Contact Shape	Contact Material	Connector Type	Pitch - Mating	Pitch - Mating	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Number of Positions	Contact Finish - Post	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Contact Length - Post [x]	Contact Length - Post [x]	Material Flammability Rating	Fastening Type	Shrouding	Style	Insulation Height	Insulation Height	Current Rating (Amps)	Contact Finish - Mating	Number of Positions Loaded	Insulation Material	Insulation Color	Number of Rows	Contact Length - Mating [x]	Contact Length - Mating [x]	Contact Type	Contact Length - Mating	Overall Contact Length	Overall Contact Length	Contact Length - Post	Contact Length - Post	Overall Contact Length	Row Spacing - Mating [x]	Row Spacing - Mating [x]
Sullins Connector Solutions PZC30SGAN	Through Hole Right Angle	Solder	Square	Copper Alloy	Header	0.1 in	2.54 mm	2.54 µm	100 µin	30	Tin	10 çin	0.25 çm	0.12 in	3.05 mm	UL94 V-0	Push-Pull	Unshrouded	Board to Board Cable	3.56 mm	0.14 in	3 A	Gold	All	Polyester Thermoplastic	Black	1	0.318 "	8.08 mm	Male Pin
Sullins Connector Solutions PZC30SBAN	Through Hole Right Angle	Solder	Square	Copper Alloy	Header	0.1 in	2.54 mm	2.54 µm	100 µin	30	Tin	10 çin	0.25 çm	0.12 in	3.05 mm	UL94 V-0	Push-Pull	Unshrouded	Board to Board Cable	3.56 mm	0.14 in	3 A	Gold	All	Polyester Thermoplastic	Black	1	0.23 in		Male Pin	5.84 mm
Sullins Connector Solutions PZC30SFEN	Through Hole	Solder	Square	Copper Alloy	Header	0.1 in	2.54 mm	2.54 µm	100 µin	30	Tin	10 çin	0.25 çm			UL94 V-0	Push-Pull	Unshrouded	Board to Board Cable	2.54 mm	0.1 in	3 A	Gold	All	Polyester Thermoplastic	Black	1	0.318 "	8.08 mm	Male Pin		0.938 in	23.83 mm	13.21 mm	0.52 "
Sullins Connector Solutions PZC30SBBN	Through Hole Right Angle	Solder	Square	Copper Alloy	Header	0.1 in	2.54 mm	2.54 µm	100 µin	30	Tin	10 çin	0.25 çm			UL94 V-0	Push-Pull	Unshrouded	Board to Board Cable	3.56 mm	0.14 in	3 A	Gold	All	Polyester Thermoplastic	Black	1	0.23 in		Male Pin	5.84 mm			5.84 mm	0.23 in
Sullins Connector Solutions PZC30SGBN	Through Hole Right Angle	Solder	Square	Copper Alloy	Header	0.1 in	2.54 mm	2.54 µm	100 µin	30	Tin	10 çin	0.25 çm			UL94 V-0	Push-Pull	Unshrouded	Board to Board Cable	3.56 mm	0.14 in	3 A	Gold	All	Polyester Thermoplastic	Black	1	0.318 "	8.08 mm	Male Pin				5.58 mm	0.22 in
Sullins Connector Solutions PZC30SACN	Through Hole	Solder	Square	Copper Alloy	Header	0.1 in	2.54 mm	2.54 µm	100 µin	30	Tin	10 çin	0.25 çm	0.32 in	8.13 mm	UL94 V-0	Push-Pull	Unshrouded	Board to Board Cable	2.54 mm	0.1 in	3 A	Gold	All	Polyester Thermoplastic	Black	1	0.23 in		Male Pin	5.84 mm		0.65 in			16.51 mm
Sullins Connector Solutions PZC30SAEN	Through Hole	Solder	Square	Copper Alloy	Header	0.1 in	2.54 mm	2.54 µm	100 µin	30	Tin	10 çin	0.25 çm			UL94 V-0	Push-Pull	Unshrouded	Board to Board Cable	2.54 mm	0.1 in	3 A	Gold	All	Polyester Thermoplastic	Black	1	0.23 in		Male Pin	5.84 mm	0.85 in	21.59 mm	13.21 mm	0.52 "
Sullins Connector Solutions PZC30DAAN	Through Hole	Solder	Square	Copper Alloy	Header	0.1 in	2.54 mm	2.54 µm	100 µin	60	Tin	10 çin	0.25 çm	0.12 in	3.05 mm	UL94 V-0	Push-Pull	Unshrouded	Board to Board Cable	2.54 mm	0.1 in	3 A	Gold	All	Polyester Thermoplastic	Black	2	0.23 in		Male Pin	5.84 mm	0.45 "	11.43 mm				2.54 mm	0.1 in
Sullins Connector Solutions PZC30DFBN	Through Hole	Solder	Square	Copper Alloy	Header	0.1 in	2.54 mm	2.54 µm	100 µin	60	Tin	10 çin	0.25 çm			UL94 V-0	Push-Pull	Unshrouded	Board to Board Cable	2.54 mm	0.1 in	3 A	Gold	All	Polyester Thermoplastic	Black	2	0.318 "	8.08 mm	Male Pin		0.638 in	16.21 mm	5.58 mm	0.22 in		2.54 mm	0.1 in
Sullins Connector Solutions PZC30SBCN	Through Hole Right Angle	Solder	Square	Copper Alloy	Header	0.1 in	2.54 mm	2.54 µm	100 µin	30	Tin	10 çin	0.25 çm	0.32 in	8.13 mm	UL94 V-0	Push-Pull	Unshrouded	Board to Board Cable	3.56 mm	0.14 in	3 A	Gold	All	Polyester Thermoplastic	Black	1	0.23 in		Male Pin	5.84 mm

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Description

General part information

PZC30 Series

Connector Header Through Hole 30 position 0.100" (2.54mm)
