AMEL6-5SVZ

Active

aimtec

AC/DC CONVERTER 5V 6W

Search across all available documentation for this part.

Active

aimtec

AC/DC CONVERTER 5V 6W

Technical Specifications

Parameters and characteristics for this part

Part	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [z]	Mounting Type	Line Regulation	Current - Output (Max) [Max]	Voltage - Output 1	Voltage - Input [Max]	Voltage - Input [Min]	Number of Outputs	Weight	Weight	Features	Applications	Power (Watts)	Package / Case	Type	Efficiency	Load Regulation
aimtec AMEL6-15SVZ	0.6 "	50.8 mm	2 in	25.4 mm	25.4 mm	15.4 mm	Through Hole	0.5 %	400 mA	15 V	264 VAC 370 VDC	85 VAC 100 V	1	31 g	0.068 lb	Universal Input	ITE (Commercial)	6 W	4-DIP Module	Enclosed	77 %	1 %
aimtec AMEL6-5SVZ	0.6 "	50.8 mm	2 in	25.4 mm	25.4 mm	15.4 mm	Through Hole	0.5 %	1.2 A	5 V	264 VAC 370 VDC	85 VAC 100 V	1	31 g	0.068 lb	Universal Input	ITE (Commercial)	6 W	4-DIP Module	Enclosed	76 %	1 %
aimtec AMEL6-3.3SVZ	0.6 "	50.8 mm	2 in	25.4 mm	25.4 mm	15.4 mm	Through Hole	0.5 %	1.25 A	3.3 V	264 VAC 370 VDC	85 VAC 100 V	1	31 g	0.068 lb	Universal Input	ITE (Commercial)	4.1 W	4-DIP Module	Enclosed	70 %	1 %
aimtec AMEL6-9SVZ	0.6 "	50.8 mm	2 in	25.4 mm	25.4 mm	15.4 mm	Through Hole	0.5 %	660 mA	9 V	264 VAC 370 VDC	85 VAC 100 V	1	31 g	0.068 lb	Universal Input	ITE (Commercial)	5.9 W	4-DIP Module	Enclosed	74 %	1 %

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

Enclosed AC DC Converters 1 Output 5V 1.2A 85 ~ 264 VAC, 100 ~ 370 VDC Input
