A17883-05

Active

Laird Technologies - Thermal Materials

THERM PAD 228.6MMX228.6MM TEAL

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

A17883-05

Active

Laird Technologies - Thermal Materials

THERM PAD 228.6MMX228.6MM TEAL

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	A17883-05

Color	Teal
Material	Silicone, Ceramic Filled
Outline [x]	228.6 mm
Outline [y]	228.6 mm
Shape	Square
Shelf Life	12 Months
Storage/Refrigeration Temperature [Max]	35 °C
Storage/Refrigeration Temperature [Min]	0 °C
Thermal Conductivity	6 W/m-K
Thickness	50 mils
Thickness	0.05 in
Type	Gap Filler Pad, Sheet

A17883 Series

Part	Type	Shelf Life	Thickness	Thickness	Color	Storage/Refrigeration Temperature [Max]	Thermal Conductivity	Outline [x]	Outline [y]	Shape	Material	Thickness [custom]
Laird Technologies - Thermal Materials A17883-15	Gap Filler Pad Sheet	12 Months	0.15 in	3.81 mm	Teal	35 °C	6 W/m-K	228.6 mm	228.6 mm	Square	Ceramic Filled Silicone
Laird Technologies - Thermal Materials A17883-16	Gap Filler Pad Sheet	12 Months	0.16 in	4.06 mm	Teal	35 °C	6 W/m-K	228.6 mm	228.6 mm	Square	Ceramic Filled Silicone
Laird Technologies - Thermal Materials A17883-19	Gap Filler Pad Sheet	12 Months		4.83 mm	Teal	35 °C	6 W/m-K	228.6 mm	228.6 mm	Square	Ceramic Filled Silicone	0.19 in
Laird Technologies - Thermal Materials A17883-17	Gap Filler Pad Sheet	12 Months	0.17 in	4.32 mm	Teal	35 °C	6 W/m-K	228.6 mm	228.6 mm	Square	Ceramic Filled Silicone
Laird Technologies - Thermal Materials A17883-05	Gap Filler Pad Sheet	12 Months	0.05 in	50 mils	Teal	35 °C	6 W/m-K	228.6 mm	228.6 mm	Square	Ceramic Filled Silicone
Laird Technologies - Thermal Materials A17883-18	Gap Filler Pad Sheet	12 Months	0.18 in	4.57 mm	Teal	35 °C	6 W/m-K	228.6 mm	228.6 mm	Square	Ceramic Filled Silicone
Laird Technologies - Thermal Materials A17883-04	Gap Filler Pad Sheet	12 Months	0.04 in	1.016 mm	Teal	35 °C	6 W/m-K	228.6 mm	228.6 mm	Square	Ceramic Filled Silicone
Laird Technologies - Thermal Materials A17883-12	Gap Filler Pad Sheet	12 Months	0.12 in	3.05 mm	Teal	35 °C	6 W/m-K	228.6 mm	228.6 mm	Square	Ceramic Filled Silicone
Laird Technologies - Thermal Materials A17883-14	Gap Filler Pad Sheet	12 Months	0.14 in	3.56 mm	Teal	35 °C	6 W/m-K	228.6 mm	228.6 mm	Square	Ceramic Filled Silicone
Laird Technologies - Thermal Materials A17883-20	Gap Filler Pad Sheet	12 Months	0.2 in	200 mils	Teal	35 °C	6 W/m-K	228.6 mm	228.6 mm	Square	Ceramic Filled Silicone

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 110.30
		10	$ 97.84
		25	$ 93.27
		50	$ 89.95
		100	$ 86.75

Description

General part information

A17883 Series

Thermal Pad Teal 228.60mm x 228.60mm Square

Documents

Technical documentation and resources
