5220UL 009U1000

Active

Belden Inc.

CABLE 2COND 16AWG WHITE

Search across all available documentation for this part.

Active

Belden Inc.

CABLE 2COND 16AWG WHITE

Technical Specifications

Parameters and characteristics for this part

Specification	5220UL 009U1000

Cable Type	Multi-Conductor
Conductor Insulation	Polypropylene (PP)
Conductor Material	Copper, Bare
Conductor Strand	Solid
Features	Rip Cord
Jacket (Insulation) Diameter [diameter]	4.22 mm
Jacket (Insulation) Diameter [diameter]	0.166 in
Jacket (Insulation) Material	Poly-Vinyl Chloride (PVC), Riser
Jacket (Insulation) Thickness	0.432 mm
Jacket (Insulation) Thickness	0.017 in
Length	1000 ft
Length	304.8 m
Number of Conductors	2
Usage	Sound, Security, Alarm
Voltage	300 V
Wire Gauge	16 AWG

Part	Number of Conductors	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Voltage	Conductor Strand	Length	Length	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Conductor Insulation	Wire Gauge	Jacket (Insulation) Material	Conductor Material	Usage	Cable Type	Features	Jacket Color
Belden Inc. 5220UL 009U1000	2	0.432 mm	0.017 in	300 V	Solid	1000 ft	304.8 m	4.22 mm	0.166 in	Polypropylene (PP)	16 AWG	Poly-Vinyl Chloride (PVC) Riser	Copper Bare	Alarm Security Sound	Multi-Conductor	Rip Cord
Belden Inc. 5220UL 0101000	2	0.432 mm	0.017 in	300 V	Solid	1000 ft	304.8 m	4.22 mm	0.166 in	Polypropylene (PP)	16 AWG	Poly-Vinyl Chloride (PVC) Riser	Copper Bare	Alarm Security Sound	Multi-Conductor	Rip Cord	Black
Belden Inc. 5220UL 0031000	2	0.432 mm	0.017 in	300 V	Solid	1000 ft	304.8 m	4.22 mm	0.166 in	Polypropylene (PP)	16 AWG	Poly-Vinyl Chloride (PVC) Riser	Copper Bare	Alarm Security Sound	Multi-Conductor	Rip Cord	Orange
Belden Inc. 5220UL 0041000	2	0.432 mm	0.017 in	300 V	Solid	1000 ft	304.8 m	4.22 mm	0.166 in	Polypropylene (PP)	16 AWG	Poly-Vinyl Chloride (PVC) Riser	Copper Bare	Alarm Security Sound	Multi-Conductor	Rip Cord	Yellow
Belden Inc. 5220UL 002A1000	2	0.432 mm	0.017 in	300 V	Solid	1000 ft	304.8 m	4.22 mm	0.166 in	Polypropylene (PP)	16 AWG	Poly-Vinyl Chloride (PVC) Riser	Copper Bare	Alarm Security Sound	Multi-Conductor	Rip Cord	Red

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Spool	1000	$ 0.27

General part information

2 Conductor Multi-Conductor Cable White 16 AWG 1000.0' (304.8m)
