Specification	PMRL200W-NWR24H-WT

Current	17 mA
Lamp Color	Red
Lens Size	5 mm
Lens Size (Code)	T-1 3/4
Lens Style	Round, Domed Top
Millicandela Rating	2800 mcd
Panel Cutout Dimension	0.31 "
Panel Cutout Shape	Round
Ratings	If (Max), Vf (Typ)
Termination Length	6 in
Termination Style	Wire Leads
Type	LED
Viewing Angle	30 °
Voltage	24 V
Wavelength - Peak	634 nm

PMRL200 Series

Part	Panel Cutout Shape	Type	Lens Size	Lens Size (Code)	Millicandela Rating	Lamp Color	Termination Length	Termination Style	Viewing Angle	Voltage	Lens Style	Current	Panel Cutout Dimension	Wavelength - Peak	Ratings
Visual Communications Company - VCC PMRL200W-BG24H-WT	Round	LED	5 mm	T-1 3/4	80 mcd	Green	6 in	Wire Leads	60 °	24 V	Domed Top Round	17 mA	0.31 "	565 nm	If (Max) Vf (Typ)
Visual Communications Company - VCC PMRL200W-NWG15H-WT	Round	LED	5 mm	T-1 3/4	2400 mcd	Green	6 in	Wire Leads	45 °	15 V	Domed Top Round	15 mA	0.31 "	520 nm	If (Max) Vf (Typ)
Visual Communications Company - VCC PMRL200W-NWR120-WT	Round	LED	5 mm	T-1 3/4	2800 mcd	Red	6 in	Wire Leads	30 °	120 V	Domed Top Round	3.5 mA	0.31 "	634 nm	AC
Visual Communications Company - VCC PMRL200W-BCR24H-WT	Round	LED	5 mm	T-1 3/4	120 mcd	Red	6 in	Wire Leads	35 °	24 V	Domed Top Round	17 mA	0.31 "	635 nm	If (Max) Vf (Typ)
Visual Communications Company - VCC PMRL200W-NWR24H-WT	Round	LED	5 mm	T-1 3/4	2800 mcd	Red	6 in	Wire Leads	30 °	24 V	Domed Top Round	17 mA	0.31 "	634 nm	If (Max) Vf (Typ)
Visual Communications Company - VCC PMRL200W-BCG24H-WT	Round	LED	5 mm	T-1 3/4	80 mcd	Green	6 in	Wire Leads	24 °	24 V	Domed Top Round	17 mA	0.31 "	565 nm	If (Max) Vf (Typ)
Visual Communications Company - VCC PMRL200W-BG5H-WT	Round	LED	5 mm	T-1 3/4	80 mcd	Green	6 in	Wire Leads	60 °	5 VDC	Domed Top Round	22 mA	0.31 "	565 nm	If (Max) Vf (Typ)
Visual Communications Company - VCC PMRL200W24-BG2-WT
Visual Communications Company - VCC PMRL200W-BCG12H-WT	Round	LED	5 mm	T-1 3/4	80 mcd	Green	6 in	Wire Leads	24 °	12 VDC	Domed Top Round	20 mA	0.31 "	565 nm	If (Max) Vf (Typ)
Visual Communications Company - VCC PMRL200W-NWG120-WT	Round	LED	5 mm	T-1 3/4	2400 mcd	Green	6 in	Wire Leads	45 °	120 V	Domed Top Round	3.5 mA	0.31 "	520 nm	AC
