C14610B0061023

Active

Amphenol Tuchel Industrial

INSERT FEMALE 6+2POS+1GND SCREW

Search across all available documentation for this part.

Active

Amphenol Tuchel Industrial

INSERT FEMALE 6+2POS+1GND SCREW

Technical Specifications

Parameters and characteristics for this part

Specification	C14610B0061023

Color	Gray
Contact Finish	Silver
Contact Material	Brass
Current Rating (Amps)	10 A
Gender	Female
Material Flammability Rating	UL94 V-0
Number of Positions [custom]	Ground
Number of Positions [custom]	6
Number of Positions [custom]	2
Operating Temperature [Max]	125 °C
Operating Temperature [Min]	-40 °C
Size	E16
Termination Style	Screw
Voltage Rating	600 V

Part	Contact Material	Size	Current Rating (Amps)	Color	Voltage Rating	Operating Temperature [Max]	Operating Temperature [Min]	Number of Positions [custom]	Number of Positions [custom]	Number of Positions [custom]	Gender	Termination Style	Material Flammability Rating	Contact Finish	Number of Positions	Connector Type	Contact Type
Amphenol Tuchel Industrial C14610B0061023	Brass	E16	10 A	Gray	600 V	125 °C	-40 °C	Ground	6	2	Female	Screw	UL94 V-0	Silver
Amphenol Tuchel Industrial C14610B0065001			10 A	Gray	600 V	125 °C	-40 °C				Female	Crimp	UL94 V-0		6+Ground	Insert without Contacts	heavy\|mate® C146 E EE

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	10	$ 16.69

General part information

Female Insert Gray 6+2+Ground Position Screw
