Technical Specifications

Parameters and characteristics commom to parts in this series

SpecificationSN74LVC08AQPWRHT74LVC08 Series
Current - Output High, Low-24 mA
Current - Output High, Low-24 mA
Current - Quiescent (Max)-1 - 10 çA
Grade-Automotive
Input Logic Level - High-1.7 V
Input Logic Level - High-2 V
Input Logic Level - Low-0.8 V
Input Logic Level - Low-0.7 V
Input Logic Level - Low-0.8 V
Logic Type-AND Gate
Max Propagation Delay @ V, Max CL-3.9 - 4.1 ns
Mounting Type-Surface Mount
null-
Number of Circuits-4
Number of Inputs-2
Operating Temperature-125 °C
Operating Temperature--55 - -40 °C
Package / Case-14-TSSOP, 14-SOIC, 14-SSOP, 14-VFQFN Exposed Pad
Package / Case-0.173 in
Package / Case-4.4 mm
Package / Case-3.9 mm
Package / Case-0.154 - 5.3 in
Package / Case-0.209 in
Package / Case-5.3 mm
Package / Case-0.209 in
Qualification-AEC-Q100
Supplier Device Package-14-TSSOP, 14-SSOP, 14-VQFN (3.5x3.5), 14-SO
Voltage - Supply-3.6 V
Voltage - Supply-1.65 - 2 V

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

74LVC08 Series

Four-channel two-input 1.65V to 3.6V AND gate
