EL-21CFR-VAC

Active

Lascar Electronics

THERMO POCKET -40-257F VACCINE

Search across all available documentation for this part.

Active

Lascar Electronics

THERMO POCKET -40-257F VACCINE

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	1	$ 250.49

General part information

Pocket -40 ~ 257°F (-40 ~ 125°C) Thermometer LCD C°/F° Data Logging, Flashlight, LED Indicator

Specification	EL-21CFR-VAC	EL-21CFR Series

Battery Cell Size	1/2AA	1/2AA
Display Type	LCD	LCD
Features	LED Indicator, Flashlight, Data Logging	LED Indicator, Flashlight, Data Logging
For Measuring	-	Humidity, Temperature
Includes	Battery, Probe, Mounting Bracket	Software, Battery, Probe, Mounting Bracket, Mounting Clip
Input Type	-	Thermocouple
Probe Type	-	K, J, T
Temperature Display	C°, F°	C°, F°
Temperature Range [Max]	125 °C	80 - 2462 °C
Temperature Range [Min]	-40 °F	-200 - -35 °F
Type	Pocket	Data Logger, Pocket

Part	Type	Includes	For Measuring	Features	Temperature Display	Display Type	Temperature Range [Min]	Temperature Range [Max]	Battery Cell Size	Probe Type	Input Type
Lascar Electronics EL-21CFR-2-LCD+	Data Logger	Battery, Software	Humidity, Temperature
Lascar Electronics EL-21CFR-VAC	Pocket	Battery, Mounting Bracket, Probe		Data Logging, Flashlight, LED Indicator	C°, F°	LCD	-40 °F	125 °C	1/2AA
Lascar Electronics EL-21CFR-1-LCD	Pocket	Battery, Mounting Bracket, Software		Data Logging, Flashlight, LED Indicator	C°, F°	LCD	-35 °C	80 °C	1/2AA
Lascar Electronics EL-21CFR-TP-LCD+	Pocket	Battery, Mounting Bracket, Probe		Data Logging, Flashlight, LED Indicator	C°, F°	LCD	-40 °F	125 °C	1/2AA
Lascar Electronics EL-21CFR-TP-LCD	Pocket	Battery, Mounting Bracket, Probe		Data Logging, Flashlight, LED Indicator	C°, F°	LCD	-40 °F	125 °C	1/2AA
Lascar Electronics EL-21CFR-2-LCD	Data Logger	Battery, Software	Humidity, Temperature
Lascar Electronics EL-21CFR-TC	Pocket	Battery, Mounting Clip		Data Logging	C°, F°		-200 °C	2462 °F	1/2AA	J, K, T	Thermocouple
