D1D07

Active

Sensata-Crydom

SSR RELAY SPST-NO 7A 0-100V

D1D07

Active

Sensata-Crydom

SSR RELAY SPST-NO 7A 0-100V

Description Specifications Series Pricing CAD Documents

Description

General part information

- Series

Solid State Relays - Industrial Mount Plug In 80VDC 5A 18-32VDC Control

Technical Specifications

Parameters and characteristics for this part

Specification	D1D07

Approval Agency	cURus, CE
Circuit	SPST-NO (1 Form A)
Load Current	7 A
Mounting Type	Chassis Mount
On-State Resistance (Max)	290 mOhms
Operating Temperature (Max)	100 °C
Operating Temperature (Min)	-40 °C
Output Type	DC
Package / Case	Hockey Puck
Termination Style	Screw Terminal
Voltage - Input (DC) Maximum	32 VDC
Voltage - Input (DC) Minimum	3.5 VDC
Voltage - Load (Max)	100 V
Voltage - Load (Min)	1 V

- Series

Solid State Relays - Industrial Mount Plug In 80VDC 5A 18-32VDC Control

...

Part	Load Current	Package / Case	Approval Agency	Operating Temperature (Max)	Operating Temperature (Min)	Mounting Type	Output Type	Circuit	Voltage - Input (DC) Minimum	Voltage - Input (DC) Maximum	Voltage - Load (Max)	Voltage - Load (Min)	Termination Style	Package Name	Quick Connect Size (0.187")	Voltage - Input (AC) Maximum	Voltage - Input (AC) Minimum	On-State Resistance (Max)
Sensata-Crydom D2402	2 A	Hockey Puck	CE CSA TUV UL	80 °C	-40 °C	Chassis Mount	AC Zero Cross	SPST-NO (1 Form A)	3 VDC	32 VDC	280 V	24 V	Screw Terminal
Sensata-Crydom UPD2415	15 A	6-SIP	CE cURus	80 °C	-40 °C	Through Hole	AC Zero Cross	SPST-NO (1 Form A)	3 VDC	32 VDC	280 V	24 V	PC Pin	6-SIP
Sensata-Crydom ED24F5	5 A	Module	CE cURus IEC	80 °C	-30 °C	Socketable	AC Zero Cross	SPST-NO (1 Form A)	48 VDC	72 VDC	280 V	24 V	Plug In Quick Connect		0.187 in
Sensata-Crydom CWU4850	50 A	Hockey Puck	CE CSA cURus TUV	80 °C	-40 °C	Chassis Mount	AC Zero Cross	SPST-NO (1 Form A)	20 VDC	48 V	660 V	48 V	Screw Terminal			280 V	20 V
Sensata-Crydom ED24B5	5 A	Module	CE cURus IEC	80 °C	-30 °C	Socketable	AC Zero Cross	SPST-NO (1 Form A)			280 V	24 V	Plug In Quick Connect		0.187 in	140 V	90 V
Sensata-Crydom S218	8 A	Module	CE CSA UL	80 °C	-30 °C	Chassis Mount	AC Zero Cross	SPST-NO (1 Form A)	3.5 VDC	8 VDC	140 V	20 V	Quick Connect		0.187 in
Sensata-Crydom ED10C5	5 A	Module	CE cURus IEC	80 °C	-30 °C	Socketable	DC	SPST-NO (1 Form A)	18 VDC	32 VDC	80 V	1 V	Plug In Quick Connect		0.187 in
Sensata-Crydom D1210	10 A	Hockey Puck	CE CSA TUV UL	80 °C	-40 °C	Chassis Mount	AC Zero Cross	SPST-NO (1 Form A)	3 VDC	32 VDC	140 V	24 V	Screw Terminal
Sensata-Crydom D1D07	7 A	Hockey Puck	CE cURus	100 °C	-40 °C	Chassis Mount	DC	SPST-NO (1 Form A)	3.5 VDC	32 VDC	100 V	1 V	Screw Terminal					290 mOhms
Sensata-Crydom HA6050	50 A	Hockey Puck	CE CSA cURus TUV	80 °C	-40 °C	Chassis Mount	AC Zero Cross	SPST-NO (1 Form A)			660 V	48 V	Screw Terminal			280 V	90 V
