CTHS15 Series

Pushbutton Switch Capacitive, Illuminated Through Hole

Technical Specifications

Parameters and characteristics for this part

Specification	CTHS15CIC05

Actuator Marking	No Marking
Actuator Type	Square, Button
Color	Green
Color - Actuator/Cap	Clear
Illumination Type	LED
Illumination Voltage (Nominal)	3.2 VDC
Mounting Type	Through Hole
Switch Function	Off-On
Termination Style	PC Pin
Type	Illuminated, Capacitive

CTHS15 Series

Part	Actuator Type	Type	Illumination Voltage (Nominal)	Switch Function	Termination Style	Mounting Type	Color - Actuator/Cap	Actuator Marking	Color	Illumination Type
Visual Communications Company - VCC CTHS15CIC07ALARM	Button Square	Capacitive Illuminated	3.2 VDC	Off-On	PC Pin	Through Hole	Black	Alarm Symbol	Yellow	LED
Visual Communications Company - VCC CTHS15CIC04ONOFF	Button Square	Capacitive Illuminated	3.2 VDC	Off-On	PC Pin	Through Hole	Black	Power Symbol	White	LED
Visual Communications Company - VCC CTHS15CIC05	Button Square	Capacitive Illuminated	3.2 VDC	Off-On	PC Pin	Through Hole	Clear	No Marking	Green	LED
Visual Communications Company - VCC CTHS15CIC06ALARM	Button Square	Capacitive Illuminated	3.2 VDC	Off-On	PC Pin	Through Hole	Black	Alarm Symbol	Blue	LED
Visual Communications Company - VCC CTHS15CIC06ARROW	Button Square	Capacitive Illuminated	3.2 VDC	Off-On	PC Pin	Through Hole	Black	Arrow Right	Blue	LED
Visual Communications Company - VCC CTHS15CIC01ONOFF	Button Square	Capacitive Illuminated	3.2 VDC	Off-On	PC Pin	Through Hole	Black	Power Symbol	Red	LED
Visual Communications Company - VCC CTHS15CIC06	Button Square	Capacitive Illuminated	3.2 VDC	Off-On	PC Pin	Through Hole	Clear	No Marking	Blue	LED
Visual Communications Company - VCC CTHS15CIC05ALARM	Button Square	Capacitive Illuminated	3.2 VDC	Off-On	PC Pin	Through Hole	Black	Alarm Symbol	Green	LED
Visual Communications Company - VCC CTHS15CIC04ARROW	Button Square	Capacitive Illuminated	3.2 VDC	Off-On	PC Pin	Through Hole	Black	Arrow Right	White	LED
Visual Communications Company - VCC CTHS15CIC07ONOFF	Button Square	Capacitive Illuminated	3.2 VDC	Off-On	PC Pin	Through Hole	Black	Power Symbol	Yellow	LED
