PP-2565-OM
ActiveCUI Devices
POWER PLUG 3 X 6.5 MM STRAIGHT
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
PP-2565-OM
ActiveCUI Devices
POWER PLUG 3 X 6.5 MM STRAIGHT
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | PP-2565-OM |
|---|---|
| Actual Diameter [diameter] | 0.118 in, 0.256 in |
| Actual Diameter [diameter] | 6.5 mm, 3 mm |
| Body Color | Silver |
| Body Material | Brass |
| Connector Type | Plug |
| Contact Material | Phosphor Bronze |
| Contact Material - Plating [custom] | Nickel |
| Current Rating (Amps) | 8 A |
| Gender | Female |
| Industry Recognized Mating Diameter [custom] | 3 mm |
| Industry Recognized Mating Diameter [custom] | 0.118 in |
| Industry Recognized Mating Diameter [custom] | 0.256 in |
| Industry Recognized Mating Diameter [custom] | 6.5 mm |
| Insulation Color | Black |
| Internal Switch(s) | False |
| Material Flammability Rating | UL94 V-0 |
| Mating Length/Depth | 0.728 in |
| Mating Length/Depth | 18.5 mm |
| Mounting Type | Free Hanging (In-Line) |
| Number of Positions/Contacts [custom] | 2 |
| Number of Positions/Contacts [custom] | 2 |
| Operating Temperature [Max] | 70 °C |
| Operating Temperature [Min] | -25 °C |
| Shielding | Unshielded |
| Termination | Solder Eyelet |
| Voltage - Rated | 20 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bag | 1 | $ 0.93 | |
| 10 | $ 0.79 | |||
| 25 | $ 0.75 | |||
| 50 | $ 0.74 | |||
| 100 | $ 0.71 | |||
| 250 | $ 0.64 | |||
| 500 | $ 0.58 | |||
| 1000 | $ 0.51 | |||
| 3000 | $ 0.47 | |||
Description
General part information
PP-2565 Series
Power Barrel Connector Plug 3.00mm ID (0.118"), 6.50mm OD (0.256") Free Hanging (In-Line)
