ASR-SMD24D4R-K

Active

Altran Magnetics, LLC

SSR RELAY SPST-NO 4A 3-28V

Search across all available documentation for this part.

Active

Altran Magnetics, LLC

SSR RELAY SPST-NO 4A 3-28V

Technical Specifications

Parameters and characteristics commom to parts in this series

SSR RELAY SPST-NO 4A 3-28V

Part	Voltage - Input	Operating Temperature [Min]	Operating Temperature [Max]	Voltage - Load [Max]	Voltage - Load [Min]	Load Current	Approval Agency	Package / Case	Output Type	Termination Style	Mounting Type	Supplier Device Package
Altran Magnetics, LLC ASR-SMD24D4N-K	5 VDC	-30 ░C	80 C	28 V	3 V	4 A	CE, cURus, TUV	Module	DC	Screw Terminal	DIN Rail
Altran Magnetics, LLC ASR-SMD48D0.1R	24 V	-30 ░C	80 C	58 V	3 V	100 mA	CE, cURus, TUV	4-SIP	DC	PC Pin	Through Hole	4-SIP
Altran Magnetics, LLC ASR-SMD24D4R-K	24 V	-30 ░C	80 C	28 V	3 V	4 A	CE, cURus, TUV	Module	DC	Screw Terminal	DIN Rail
Altran Magnetics, LLC ASR-SMD48D3P-K	12 VDC	-30 ░C	80 C	58 V	3 V	3 A	CE, cURus, TUV	Module	DC	Screw Terminal	DIN Rail
Altran Magnetics, LLC ASR-SMD48D0.1T	60 VDC	-30 ░C	80 C	58 V	3 V	100 mA		4-SIP	DC	PC Pin	Through Hole	4-SIP
Altran Magnetics, LLC ASR-SMD48D0.1P	12 VDC	-30 ░C	80 C	58 V	3 V	100 mA	CE, cURus, TUV	4-SIP	DC	PC Pin	Through Hole	4-SIP

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Solid State SPST-NO (1 Form A) Module

Technical documentation and resources
