1-87309-2
ActiveTE Connectivity AMP Connectors
CONN SOCKET 20-24AWG CRIMP GOLD
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | 1-87309-2 | 87309 Series |
|---|---|---|
| Contact Finish | Gold | Tin, Gold |
| Contact Finish Thickness | 15 µin | 15 - 50 µin |
| Contact Finish Thickness | 0.38 µm | 0.38 - 1.27 µm |
| Contact Termination | Crimp | Crimp |
| Pin or Socket | Socket | Socket |
| Wire Gauge [Max] | 24 AWG | 24 AWG |
| Wire Gauge [Min] | 20 AWG | 20 AWG |
87309 Series
CONN SOCKET 20-24AWG CRIMP TIN
| Part | Contact Termination | Pin or Socket | Wire Gauge [Min] | Wire Gauge [Max] | Contact Finish | Contact Finish Thickness | Contact Finish Thickness |
|---|---|---|---|---|---|---|---|
TE Connectivity AMP Connectors 87309-8 | Crimp | Socket | 20 AWG | 24 AWG | Tin | 50 µin | 1.27 µm |
TE Connectivity AMP Connectors 87309-3 | Crimp | Socket | 20 AWG | 24 AWG | Gold | 30 Áin | 0.76 Ám |
TE Connectivity AMP Connectors 1-87309-4 | Crimp | Socket | 20 AWG | 24 AWG | Gold | 30 Áin | 0.76 Ám |
TE Connectivity AMP Connectors 87309-9 | Crimp | Socket | 20 AWG | 24 AWG | Gold | 30 Áin | 0.76 Ám |
TE Connectivity AMP Connectors 87309-2 | Crimp | Socket | 20 AWG | 24 AWG | Tin | 50 µin | 1.27 µm |
TE Connectivity AMP Connectors 1-87309-2 | Crimp | Socket | 20 AWG | 24 AWG | Gold | 15 µin | 0.38 µm |
