5403UE 0081000

Active

Belden Inc.

CABLE 5COND 20AWG GRAY

Search across all available documentation for this part.

Active

Belden Inc.

CABLE 5COND 20AWG GRAY

Technical Specifications

Parameters and characteristics for this part

Specification	5403UE 0081000

Cable Type	Multi-Conductor
Conductor Insulation	Polypropylene (PP)
Conductor Material	Copper, Bare
Conductor Strand [custom]	28
Conductor Strand [custom]	7
Features	Rip Cord
Jacket (Insulation) Diameter [diameter]	4.29 mm
Jacket (Insulation) Diameter [diameter]	0.169 in
Jacket (Insulation) Material	Poly-Vinyl Chloride (PVC), Riser
Jacket (Insulation) Thickness	0.432 mm
Jacket (Insulation) Thickness	0.017 in
Jacket Color	Gray
Length	1000 ft
Length	304.8 m
Number of Conductors	5
Ratings	UL Style CMR
Usage	Sound, Security
Voltage	300 V
Wire Gauge	20 AWG

Part	Wire Gauge	Voltage	Cable Type	Conductor Insulation	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Conductor Strand [custom]	Conductor Strand [custom]	Usage	Conductor Material	Ratings	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Features	Number of Conductors	Jacket (Insulation) Material	Jacket Color	Length	Length
Belden Inc. 5403UE 0081000	20 AWG	300 V	Multi-Conductor	Polypropylene (PP)	0.432 mm	0.017 in	28	7	Security Sound	Copper Bare	UL Style CMR	4.29 mm	0.169 in	Rip Cord	5	Poly-Vinyl Chloride (PVC) Riser	Gray	1000 ft	304.8 m

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

5 Conductor Multi-Conductor Cable Gray 20 AWG 1000.0' (304.8m)
