2043-2X12G00DNT-P

Active

Oupiin

PCB SOCKET, DOUBLE ROW, 24 PIN,

Deep-Dive with AI

Search across all available documentation for this part.

2043-2X12G00DNT-P

Active

Oupiin

PCB SOCKET, DOUBLE ROW, 24 PIN,

Deep-Dive with AI

Specifications Pricing Series Description Documents

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tape & Reel (TR)	1	$ 2.30
		500	$ 1.92
		1000	$ 1.53
		1500	$ 1.30
		2000	$ 1.15

Description

General part information

2043 Series

24 Position Socket Connector 0.100" (2.54mm) Surface Mount Gold

Documents

Technical documentation and resources

No documents available

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	2043-2X12G00DNT-P	2043 Series

Connector Type	Socket	Socket
Contact Finish - Mating	Gold	Gold
Contact Finish - Post	Gold	Gold
Contact Finish Thickness - Mating	Flash	Flash
Contact Finish Thickness - Post	Flash	Flash
Contact Length - Post	-	3.2 mm
Contact Length - Post	-	0.126 in
Contact Material	Copper Alloy	Copper Alloy
Contact Shape	Square	Square
Contact Type	Female Socket	Female Socket
Current Rating (Amps)	2 A	2 A
Fastening Type	Push-Pull	Push-Pull
Features	Pick and Place, Board Guide	Pick and Place, Board Guide
Insulation Height	0.28 in	0.28 in
Insulation Height	7.1 mm	7.1 mm
Insulation Material	Plastic	Thermoplastic, Glass Filled, Polyester, Plastic
Material Flammability Rating	UL94 V-0	UL94 V-0
Mounting Type	Surface Mount	Through Hole, Surface Mount
Number of Positions	24	6 - 50
Number of Positions	-	16
Number of Positions Loaded	All	All
Number of Rows	2	1 - 2
Operating Temperature [Max]	105 ░C	105 ░C
Operating Temperature [Min]	-55 °C	-55 °C
Pitch - Mating	0.1 in	0.1 in
Pitch - Mating	2.54 mm	2.54 mm
Row Spacing - Mating [x]	2.54 mm	2.54 mm
Row Spacing - Mating [x]	0.1 in	0.1 in
Termination	Solder	Solder

2043 Series

2.54MM 2.54MM DOUBLE ROW GOLD 2A 10P -55℃~+105℃ COPPER ALLOY STRAIGHT 7.1MM SQUARE HOLE PLUGIN,P=2.54MM FEMALE HEADERS ROHS

Part	Contact Type	Current Rating (Amps)	Material Flammability Rating	Contact Length - Post	Contact Length - Post [x]	Mounting Type	Insulation Height	Insulation Height	Fastening Type	Connector Type	Operating Temperature [Max]	Operating Temperature [Min]	Insulation Material	Contact Finish Thickness - Mating	Contact Material	Number of Positions Loaded	Contact Finish - Post	Contact Finish Thickness - Post	Termination	Contact Finish - Mating	Pitch - Mating	Pitch - Mating	Number of Positions	Row Spacing - Mating [x]	Row Spacing - Mating [x]	Contact Shape	Number of Rows	Features	Number of Positions
Oupiin 2043-2X05G00SA	Female Socket	2 A	UL94 V-0	3.2 mm	0.126 in	Through Hole	0.28 in	7.1 mm	Push-Pull	Socket	105 ░C	-55 °C	Glass Filled, Polyester, Thermoplastic	Flash	Copper Alloy	All	Gold	Flash	Solder	Gold	0.1 in	2.54 mm	10	2.54 mm	0.1 in	Square	2
Oupiin 2043-2X25G00SA	Female Socket	2 A	UL94 V-0	3.2 mm	0.126 in	Through Hole	0.28 in	7.1 mm	Push-Pull	Socket	105 ░C	-55 °C	Glass Filled, Polyester, Thermoplastic	Flash	Copper Alloy	All	Gold	Flash	Solder	Gold	0.1 in	2.54 mm	50	2.54 mm	0.1 in	Square	2
Oupiin 2043-2X12G00DNT-P	Female Socket	2 A	UL94 V-0			Surface Mount	0.28 in	7.1 mm	Push-Pull	Socket	105 ░C	-55 °C	Plastic	Flash	Copper Alloy	All	Gold	Flash	Solder	Gold	0.1 in	2.54 mm	24	2.54 mm	0.1 in	Square	2	Board Guide, Pick and Place
Oupiin 2043-2X06G00SA	Female Socket	2 A	UL94 V-0	3.2 mm	0.126 in	Through Hole	0.28 in	7.1 mm	Push-Pull	Socket	105 ░C	-55 °C	Glass Filled, Polyester, Thermoplastic	Flash	Copper Alloy	All	Gold	Flash	Solder	Gold	0.1 in	2.54 mm	12	2.54 mm	0.1 in	Square	2
Oupiin 2043-1X16G00SA	Female Socket	2 A	UL94 V-0	3.2 mm	0.126 in	Through Hole	0.28 in	7.1 mm	Push-Pull	Socket	105 ░C	-55 °C	Glass Filled, Polyester, Thermoplastic	Flash	Copper Alloy	All	Gold	Flash	Solder	Gold	0.1 in	2.54 mm				Square	1		16
Oupiin 2043-2X03G00SA	Female Socket	2 A	UL94 V-0	3.2 mm	0.126 in	Through Hole	0.28 in	7.1 mm	Push-Pull	Socket	105 ░C	-55 °C	Glass Filled, Polyester, Thermoplastic	Flash	Copper Alloy	All	Gold	Flash	Solder	Gold	0.1 in	2.54 mm	6	2.54 mm	0.1 in	Square	2
Oupiin 2043-2X04G00SB	Female Socket	2 A	UL94 V-0	3.2 mm	0.126 in	Through Hole	0.28 in	7.1 mm	Push-Pull	Socket	105 ░C	-55 °C	Glass Filled, Polyester, Thermoplastic	Flash	Copper Alloy	All	Gold	Flash	Solder	Gold	0.1 in	2.54 mm	8			Square	1
Oupiin 2043-2X16G00SA	Female Socket	2 A	UL94 V-0	3.2 mm	0.126 in	Through Hole	0.28 in	7.1 mm	Push-Pull	Socket	105 ░C	-55 °C	Glass Filled, Polyester, Thermoplastic	Flash	Copper Alloy	All	Gold	Flash	Solder	Gold	0.1 in	2.54 mm		2.54 mm	0.1 in	Square	2
Oupiin 2043-1X10G00SA	Female Socket	2 A	UL94 V-0	3.2 mm	0.126 in	Through Hole	0.28 in	7.1 mm	Push-Pull	Socket	105 ░C	-55 °C	Glass Filled, Polyester, Thermoplastic	Flash	Copper Alloy	All	Gold	Flash	Solder	Gold	0.1 in	2.54 mm	10			Square	1
