FAN.00.250.CLA

Active

LEMO

CONN NIMCAMA PLG STR 50OHM SOLDR

Search across all available documentation for this part.

Active

LEMO

CONN NIMCAMA PLG STR 50OHM SOLDR

Technical Specifications

Parameters and characteristics for this part

CONN NIMCAMA PLG STR 50OHM SOLDR

Part	Ingress Protection	Impedance	Body Material	Voltage Rating	Center Contact Material	Mating Cycles	Fastening Type	Body Finish	Housing Color	Number of Ports	Mounting Feature	Includes	Connector Type	Connector Style	Shield Termination	Contact Termination	Dielectric Material	Operating Temperature [Min]	Operating Temperature [Max]	Center Contact Plating
LEMO FAN.00.250.CLA	IP50	50 Ohms	Brass	700 VDC	Brass	5000	Push-Pull	Chrome	Silver	1	Bulkhead - Rear Side Nut	1 Connector, 1 Nut	Male Pin, Plug	NIM-CAMAC CD/N 549	Solder	Solder Cup	Polyetheretherketone (PEEK)	-55 °C	260 ░C	Gold

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

NIM-CAMAC CD/N 549 Connector Plug, Male Pin 50 Ohms Panel Mount Solder Cup
