PBA15F-48-N

Active

Cosel USA, Inc.

AC/DC CONVERTER 48V 15W

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

PBA15F-48-N

Active

Cosel USA, Inc.

AC/DC CONVERTER 48V 15W

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	PBA15F-48-N

Applications	ITE (Commercial)
Approval Agency	cURus, CE, TUV
Current - Output 1	350 mA
Efficiency	78 %
Features	Universal Input, DC Input Capable
Minimum Load Required	False
Mounting Type	Chassis Mount
Number of Outputs	1
Power (Watts)	15 W
Type	Enclosed
Voltage - Output 1	48 V

PBA15 Series

...

Part	Voltage - Isolation	Efficiency	Type	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [z]	Applications	Approval Agency	Mounting Type	Voltage - Output 1	Operating Temperature [Min]	Operating Temperature [Max]	Current - Output 1	Number of Outputs	Features	Power (Watts)
Cosel USA, Inc. PBA15F-48-EN	3000 V	78 %	Enclosed	31 mm	1.22 "	85.1 mm	3.35 in	3.07 in	78 mm	ITE (Commercial)	CE cURus TUV	Chassis Mount	48 V	-10 °C	71 °C	350 mA	1
Cosel USA, Inc. PBA15F-12-CT	3000 V	78 %	Open Frame	31 mm	1.22 "	85.1 mm	3.35 in	3.07 in	78 mm	ITE (Commercial)	CE cURus TUV	Chassis Mount	12 V	-10 °C	71 °C	1.3 A	1
Cosel USA, Inc. PBA15F-3R3-G	3000 V	68 %	Open Frame	31 mm	1.22 "	85.1 mm	3.35 in	3.07 in	78 mm	ITE (Commercial)	CE cURus TUV	Chassis Mount	3.3 V	-10 °C	71 °C	3 A	1
Cosel USA, Inc. PBA15F-9-T	3000 V	77 %	Open Frame	31 mm	1.22 "	85.1 mm	3.35 in	3.07 in	78 mm	ITE (Commercial)	CE cURus TUV	Chassis Mount	9 V	-10 °C	71 °C	1.7 A	1
Cosel USA, Inc. PBA15F-5-GN1	3000 V	75 %	Enclosed	31 mm	1.22 "	85.1 mm	3.35 in	3.07 in	78 mm	ITE (Commercial)	CE cURus TUV	Chassis Mount	5 V	-10 °C	71 °C	3 A	1
Cosel USA, Inc. PBA15F-12-V	3000 V	78 %	Open Frame	31 mm	1.22 "	85.1 mm	3.35 in	3.07 in	78 mm	ITE (Commercial)	CE cURus TUV	Chassis Mount	12 V	-10 °C	71 °C	1.3 A	1
Cosel USA, Inc. PBA15F-12-N1	3000 V	78 %	Enclosed	31 mm	1.22 "	85.1 mm	3.35 in	3.07 in	78 mm	ITE (Commercial)	CE cURus TUV	Chassis Mount	12 V	-10 °C	71 °C	1.3 A	1
Cosel USA, Inc. PBA15F-3R3-JN	3000 V	68 %	Enclosed	31 mm	1.22 "	85.1 mm	3.35 in	3.07 in	78 mm	ITE (Commercial)	CE cURus TUV	Chassis Mount	3.3 V	-10 °C	71 °C	3 A	1
Cosel USA, Inc. PBA15F-48-VN	3000 V	78 %	Enclosed	31 mm	1.22 "	85.1 mm	3.35 in	3.07 in	78 mm	ITE (Commercial)	CE cURus TUV	Chassis Mount	48 V	-10 °C	71 °C	350 mA	1
Cosel USA, Inc. PBA15F-48-N		78 %	Enclosed							ITE (Commercial)	CE cURus TUV	Chassis Mount	48 V			350 mA	1	DC Input Capable Universal Input	15 W

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	1	$ 53.64

Description

General part information

PBA15 Series

Enclosed AC DC Converters 1 Output 48V 85 ~ 264 VAC Input
