Description
General part information
1000 Series
Slide Switches
Documents
Technical documentation and resources
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
General part information
Slide Switches
Technical documentation and resources
Parameters and characteristics commom to parts in this series
| Specification | 1085254 | 1000 Series |
|---|---|---|
| Configuration | Fixed | Fixed |
| Connector Type | RJ45 | RJ45 |
| Copper Ports | 5 | 5 - 16 |
| Copper Type | 1000, 10, 100 | 10/100, 1000, 10, 100 |
| Ingress Protection | IP30 | IP30 |
| Mounting Type | DIN Rail | DIN Rail |
| Number of Ports | 5 | 5 - 8 |
| Number of Ports | - | 16 |
| Operating Temperature [Max] | 60 °C | 60 °C |
| Operating Temperature [Min] | -10 °C | -10 °C |
| Type | Switch | Switch |
| Voltage - Input [Max] | 32 V | 32 V |
| Voltage - Input [Min] | 9 VDC | 9 VDC |
Slide Switches
| Part | Ingress Protection | Connector Type | Configuration | Copper Ports | Operating Temperature [Min] | Operating Temperature [Max] | Number of Ports [custom] | Mounting Type | Type | Voltage - Input [Max] | Voltage - Input [Min] | Copper Type | Number of Ports |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Phoenix Contact 1085255 | IP30 | RJ45 | Fixed | 16 | -10 °C | 60 °C | 16 | DIN Rail | Switch | 32 V | 9 VDC | 10/100 | |
Phoenix Contact 1085254 | IP30 | RJ45 | Fixed | 5 | -10 °C | 60 °C | DIN Rail | Switch | 32 V | 9 VDC | 10, 100, 1000 | 5 | |
Phoenix Contact 1085243 | IP30 | RJ45 | Fixed | 8 | -10 °C | 60 °C | DIN Rail | Switch | 32 V | 9 VDC | 10, 100, 1000 | 8 |
