F6025S24B-RSR

Active

Mechatronics Fan Group

FAN AXIAL 60X25MM 24VDC WIRE

Search across all available documentation for this part.

Active

Mechatronics Fan Group

FAN AXIAL 60X25MM 24VDC WIRE

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	100	$ 8.54

General part information

Fan Tubeaxial 24VDC Square - 60mm L x 60mm H Ball 12.0 CFM (0.336m³/min) 2 Wire Leads

Technical documentation and resources

Parameters and characteristics commom to parts in this series

Specification	F6025S24B-RSR	F6025S24B Series

Air Flow	0.336 mł/min	0.336 mł/min
Air Flow	12 CFM	12 CFM
Approval Agency	CE, cUL, TUV, UL	CE, cUL, TUV, UL
Bearing Type	Ball	Ball
Current Rating (Amps)	40 mA	40 mA
Fan Type	Tubeaxial	Tubeaxial
Features	Locked Rotor Protection, Auto Restart	Locked Rotor Protection, Auto Restart, Speed Sensor (Tach)
Material - Blade	Polybutylene Terephthalate (PBT)	Polybutylene Terephthalate (PBT)
Noise	22 dB(A)	22 dB(A)
RPM	2300 RPM	2300 RPM
Size / Dimension [x]	60 mm	60 mm
Size / Dimension [y]	60 mm	60 mm
Static Pressure	17.4 Pa	17.4 - 22.4 Pa
Static Pressure	0.07 in H2O	0.07 - 0.09 in H2O
Termination	2 Wire Leads	2 Wire Leads, 3 Wire Leads
Voltage - Rated	24 VDC	24 VDC
Weight	63.05 g	63.05 g
Weight	0.139 lb	0.139 lb
Width [y]	25 mm	25 mm

FAN AXIAL 60X25MM 24VDC WIRE

Part	Static Pressure	Static Pressure	Features	Weight	Weight	Fan Type	Size / Dimension [x]	Size / Dimension [y]	Noise	Air Flow	Air Flow	Approval Agency	Width [y]	Current Rating (Amps)	Bearing Type	Voltage - Rated	Termination	RPM	Material - Blade
Mechatronics Fan Group F6025S24B-RSR	17.4 Pa	0.07 in H2O	Auto Restart, Locked Rotor Protection	63.05 g	0.139 lb	Tubeaxial	60 mm	60 mm	22 dB(A)	0.336 mł/min	12 CFM	CE, cUL, TUV, UL	25 mm	40 mA	Ball	24 VDC	2 Wire Leads	2300 RPM	Polybutylene Terephthalate (PBT)
Mechatronics Fan Group F6025S24B1-RSR	17.4 Pa	0.07 in H2O	Auto Restart, Locked Rotor Protection, Speed Sensor (Tach)	63.05 g	0.139 lb	Tubeaxial	60 mm	60 mm	22 dB(A)	0.336 mł/min	12 CFM	CE, cUL, TUV, UL	25 mm	40 mA	Ball	24 VDC	3 Wire Leads	2300 RPM	Polybutylene Terephthalate (PBT)
Mechatronics Fan Group F6025S24B-RS	22.4 Pa	0.09 in H2O	Auto Restart, Locked Rotor Protection	63.05 g	0.139 lb	Tubeaxial	60 mm	60 mm	22 dB(A)	0.336 mł/min	12 CFM	CE, cUL, TUV, UL	25 mm	40 mA	Ball	24 VDC	2 Wire Leads	2300 RPM	Polybutylene Terephthalate (PBT)
