Specification	PB-120N-27P

Approval Agency	GS, CB, cULus, CE
Battery Cell Voltage	24 V
Battery Chemistry	Lead Acid
Charge Current - Max	4.3 A
Features	LED Indicator
Mounting Type	Chassis Mount
Number of Cells	1
Operating Temperature (Max)	45 °C
Operating Temperature (Min)	-10 °C
Power - Max	118.68 W
Size / Dimension Height	1.3 in
Size / Dimension Length	5.67 in
Size / Dimension Width	3.54 in
Termination Style	Rectangular Connector
Type	Open Frame
Voltage - Input (Range 1) Maximum	132 V
Voltage - Input (Range 1) Minimum	88 V
Voltage - Input (Range 2) Maximum	264 VAC
Voltage - Input (Range 2) Minimum	176 V
Voltage - Nominal	27.6 V
Weight	1100 g

PB-120 Series

Part	Approval Agency	Weight	Operating Temperature (Min)	Operating Temperature (Max)	Power - Max	Size / Dimension Height	Size / Dimension Length	Size / Dimension Width	Features	Battery Cell Voltage	Voltage - Nominal	Mounting Type	Battery Chemistry	Termination Style	Charge Current - Max	Number of Cells	Type	Voltage - Input (Range 1) Maximum	Voltage - Input (Range 2) Minimum	Voltage - Input (Range 1) Minimum	Voltage - Input (Range 2) Maximum	Pin Count
MEAN WELL USA Inc. PB-120N-27P	CB CE cULus GS	1100 g	-10 °C	45 °C	118.68 W	1.3 in	5.67 in	3.54 in	LED Indicator	24 V	27.6 V	Chassis Mount	Lead Acid	Rectangular Connector	4.3 A	1	Open Frame	132 V	176 V	88 V	264 VAC
MEAN WELL USA Inc. PB-120N-54C	CB CE cULus GS	1100 g	-10 °C	45 °C	121.44 W	1.93 in	7.09 in	3.78 in	LED Indicator	54 V	55.2 V	Desktop	Lead Acid	DIN	2.2 A	1	Enclosed	132 V	176 V	88 V	264 VAC	3 pins
MEAN WELL USA Inc. PB-120N-54P	CB CE cULus GS	1100 g	-10 °C	45 °C	121.44 W	1.3 in	5.67 in	3.54 in	LED Indicator	54 V	55.2 V	Chassis Mount	Lead Acid	Rectangular Connector	2.2 A	1	Open Frame	132 V	176 V	88 V	264 VAC
MEAN WELL USA Inc. PB-120P-27C	CB CE cULus GS	1240 g	-10 °C	45 °C	118.68 W	1.93 in	7.09 in	3.78 in	LED Indicator	24 V	27.6 V	Desktop	Lead Acid	DIN	4.3 A	1	Enclosed	132 V	176 V	88 V	264 VAC	3 pins
MEAN WELL USA Inc. PB-120N-13C	CB CE cULus GS	1100 g	-10 °C	45 °C	99.36 W	1.93 in	7.09 in	3.78 in	LED Indicator	12 V	13.8 V	Desktop	Lead Acid	XLR	7.2 A	1	Enclosed	132 V	176 V	88 V	264 VAC	3 pins
MEAN WELL USA Inc. PB-120P-13C	CB CE cULus GS	1240 g	-10 °C	45 °C	99.36 W	1.93 in	7.09 in	3.78 in	LED Indicator	12 V	13.8 V	Desktop	Lead Acid	DIN	7.2 A	1	Enclosed	132 V	176 V	88 V	264 VAC	3 pins
MEAN WELL USA Inc. PB-120N-27C	CB CE cULus GS	1100 g	-10 °C	45 °C	118.68 W	1.93 in	7.09 in	3.78 in	LED Indicator	24 V	27.6 V	Desktop	Lead Acid	XLR	4.3 A	1	Enclosed	132 V	176 V	88 V	264 VAC	3 pins
